What to do if my JLG X770AJ-X26JP Boom Lifts battery charger shows error code 252 (short-circuit in output)?
If the battery charger displays error code 252, indicating a short-circuit in the battery charger output, turn off the battery charger and resolve the short-circuit at the output.
What to do if my JLG Boom Lifts battery charger shows error code 244 because the mains voltage is too low?
If the battery charger shows error code 244, indicating that the mains voltage is lower than the maximum operating range tolerance, make sure the mains voltage is within the correct operating parameters. The battery charger won’t start charging until the mains voltage returns within the normal operating range.
What to do if my JLG X770AJ-X26JP Boom Lifts battery charger shows error code 240 because digital input is open?
If the battery charger displays error code 240, indicating that the digital input is open, the battery charger will stop charging until the digital input closes. Close the digital input to resolve this issue.
What to do if JLG X770AJ-X26JP Boom Lifts show Inverter Error Code 8 - Watch Dog?
If the JLG Boom Lifts shows Inverter Error Code 8 - Watch Dog, check the control connections and continuity of the electric motor. If they are OK, replace the inverter, because the inverter is not able to activate or turn off the electric motor.
What to do if JLG Boom Lifts show Inverter Error Code 19 - Logic failure #1?
If JLG Boom Lifts shows Inverter Error Code 19 - Logic failure #1, it is usually a temporary anomaly due to a working condition, caused by an overvoltage or a sudden voltage drop. However, if the anomaly persists, replace the inverter.
What to do if JLG X770AJ-X26JP show Inverter Error Code 16 - Aux output KO?
If JLG Boom Lifts shows Inverter Error Code 16 - Aux output KO, it is usually a temporary anomaly due to a working condition, caused by electromechanical brake problem. In case the anomaly persists replace the inverter.
What to do if JLG Boom Lifts show Inverter Error Code 8 - Flash Checksum?
If JLG Boom Lifts shows Inverter Error Code 8 - Flash Checksum, replace the inverter, because the software is corrupted or the inverter is damaged.
What to do if JLG X770AJ-X26JP Boom Lifts show Inverter Error Code 13 - Eeprom KO?
If JLG Boom Lifts shows Inverter Error Code 13 - Eeprom KO, replace the inverter, because there is a hardware or software problem in Eeprom.
What to do if JLG X770AJ-X26JP Boom Lifts show Inverter Error Code 18 - Logic failure #2?
If JLG Boom Lifts shows Inverter Error Code 18 - Logic failure #2, replace the inverter, because there is a fault in the inverter.
What causes BMS fault code 02 - Unexpected Voltage in JLG X770AJ-X26JP?
BMS fault code 02, "Unexpected Voltage," in JLG Boom Lifts is caused by the BMS failing to identify one cell or being unable to connect it to the discharging resistance. When one cell reaches 3650 mV, the BMS will disconnect the lithium pack, triggering this error.
General| Brand | JLG |
|---|---|
| Model | X770AJ-X26JP |
| Category | Boom Lifts |
| Language | English |
Provides essential safety guidelines for operating and maintaining the Lithium ION system and machine.
Details the history of changes and updates made to the manual, starting with the original issue.
Outlines the various lithium system models and their corresponding battery pack and machine arrangements.
Illustrates the physical arrangement of components within the battery pack for different models.
Explains the 12V power system and its components, essential for machine operation and charging.
Describes how the various components of the power pack work together during machine operation.
Details the functions and operation of the BMS, crucial for monitoring and managing Li-Ion battery health.
Describes the characteristics, specifications, and features of individual lithium battery cells used in the packs.
Explains the system designed to manage the temperature of the battery pack to ensure optimal performance.
Details the function and operation of the heating system used in 3rd generation battery packs.
Covers the specifications and operation of the battery charger responsible for charging the Li-Ion battery packs.
Details the function of various relays used within the battery system for controlling power and signals.
Provides a procedure for activating the electric motor in emergency situations by bypassing safety systems.
Lists and explains various fault codes generated by the battery charger, inverter, and BMS for diagnostics.
Specifically details error codes related to the Battery Management System for 1st and 2nd generation packs.
Lists and describes fault codes associated with the inverter, along with corrective actions.
Details fault codes specific to the battery charger for 38V, 48V, 72V, and 83V battery packs.
Offers guidance for diagnosing and resolving issues specifically with the 1st and 2nd generation battery systems.
Explains how to use the RamHino diagnostic tool for detailed analysis of the lithium battery pack status.
