Table 7: Advanced Terminal Unit Controller Physical Features
Callout Physical Feature: Description and Reference
A IP 20 cover screw attachment holes
B Configurable outputs
C 24 VAC out
D 5 A relay outputs
E DIN clips
F Triac outputs
G 10 A relay output
H 240 VAC power input
I FC Bus
J FC Bus EOL switch
K SA Bus
L SA Bus RJ12
M USB
N Universal inputs
O Binary inputs
P Cover screw
Q Address switch
R Status LEDs
Figure 7: Controller and Mounting Dimensions, mm (in.)
ATC1510 Advanced Terminal Unit Controller Installation Guide 17
