Technical specifications
Table 9: CVM03050 Controllers technical specification
Product code numbers
F4-CVM03050-0
VAV Box Controller with Integrated Actuator and Digital
Differential Pressure Transducer (DPT) Sensor.
Includes MS/TP(and N2) communication; 8 points (3 UI, 2 CO,
and 3 BO); real-time clock; 32-bit microprocessor; 24VAC input.
F4-CVM03050-0P
VAV Box Controller with Integrated Actuator, Position Feedback,
and DPT Sensor.
Includes MS/TP (and N2) communication; 8 points (3 UI, 3 BO,
and 2 CO); real-time clock and 32-bit microprocessor; 24VAC
input.
Note: The following CVM03050 models are also available:
• Bulk Pack Models: F4-CVM03050-0D, F4-CVM03050-0PD
Power Requirement
24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz,
Power Supply Class 2 (North America), Safety Extra-Low Voltage
(SELV) (Europe)
Power Consumption
10 VA typical, 14 VA maximum
1
Note: The USB feature is not currently supported.
Power Source
+15 VDC power source terminals provide 35 mA total current.
Quantity 1 located in Universal IN terminals - for active (3-wire)
input devices
Ambient Conditions
Operating: 0°C to 50°C (32°F to 122°F)
Storage: -40°C to 70°C (-40°F to 158°F)
Communications Protocol
BACnet MS/TP; N2. Wireless also supported (at FC Bus and for
Sensors) with additional hardware.
Device Addressing for BACnet
MS/TP
Decimal address set via three rotary switches; valid controller
device addresses 4-127
Device Addressing for N2
Decimal address set via three rotary switches: valid controller
device addresses 1-254
F4-CVM VAV Terminal Equipment Controllers Installation Instructions32
