10 FX20/60 Supervisory Controllers Installation Instructions
Table 3: COM Port and Option Slot Assignments for FX20/FX60 Option Cards
Option Slot 1 Option Slot 2 Onboard RS232 Onboard RS485
None None COM1 COM2
RS-232 = COM3 None COM1 COM2
RS-232 = COM3 RS-232 = COM4 COM1 COM2
RS-232 = COM3 RS-485 = COM4, COM5 COM1 COM2
RS-232 = COM3 LON = LON1 COM1 COM2
RS-232 = COM3 Sedona = COM4 COM1 COM2
RS-232 = COM3 GPRS = COM4,COM5 COM1 COM2
RS-485 = COM3, COM4 None COM1 COM2
RS-485 = COM3, COM4 RS-232 = COM5 COM1 COM2
RS-485 = COM3, COM4 RS-485 = COM5, COM6 COM1 COM2
RS-485 = COM3, COM4 LON = LON1 COM1 COM2
RS-485 = COM3, COM4 Sedona = COM5 COM1 COM2
RS-485 = COM3, COM4 GPRS = COM5, COM6 COM1 COM2
LON = LON1 None COM1 COM2
LON = LON1 RS-232 = COM3 COM1 COM2
LON = LON1 RS-485 = COM3, COM4 COM1 COM2
LON = LON1 LON = LON2 COM1 COM2
LON = LON1 Sedona = COM3 COM1 COM2
LON = LON1 GPRS = COM3, COM4 COM1 COM2
Wireless TEC = COM1 None Disabled COM2
Wireless TEC = COM1 RS-232 = COM3 Disabled COM2
Wireless TEC = COM1 RS-485 = COM3, COM4 Disabled COM2
Wireless TEC = COM1 LON = LON1 Disabled COM2
Wireless TEC = COM1 Sedona = COM3 Disabled COM2
Wireless TEC = COM1 GPRS = COM3, COM4 Disabled COM2
Sedona = COM3 None COM1 COM2
Sedona = COM3 RS-232 = COM4 COM1 COM2
Sedona = COM3 RS-485 = COM4, COM5 COM1 COM2
Sedona = COM3 LON = LON1 COM1 COM2
Sedona = COM3 GPRS = COM4,COM5 COM1 COM2
Modem = COM1 None Disabled COM2
Modem = COM1 RS-232 = COM3 Disabled COM2
Modem = COM1 RS-485 = COM3, COM4 Disabled COM2
Modem = COM1 LON = LON1 Disabled COM2
Modem = COM1 Sedona = COM3 Disabled COM2
Modem = COM1 GPRS = COM3, COM4 Disabled COM2
GPRS = COM3, COM4 None COM1 COM2
GPRS = COM3, COM4 RS-232 = COM5 COM1 COM2
GPRS = COM3, COM4 RS-485 = COM5, COM6 COM1 COM2
GPRS = COM3, COM4 LON = LON1 COM1 COM2
GPRS = COM3, COM4 SEDONA = COM5 COM1 COM2
