Johnson Controls FCP-NA-701-L User Manual

Technical specifications
Table 10: FCP non-programmable and programmable FCU or PTAC Thermostats technical
specifications
Specification Description
Models Non-programmable: FCP-NA-701-L
Programmable: FCP-PA-701-L
Power requirements 20 VAC to 30 VAC, 60 Hz, max. 3 A (3 VA at 24 V nominal)
Output rating Valve and fan
outputs
1 A maximum per each relay channel
(Max. relays ON combination: 3 relays), 20 VAC to 30 VAC
Remote sensor 10K ohm at 77°F (25°C) NTC sensor
Pipe sensor 10K ohm at 77°F (25°C) NTC sensor
Analog inputs
Set back NC/NO dry contact switch
Local temperature sensor type NTC temperature sensor, accurate to ±1°F (±0.6°C) at 77°F (25°C)
Remote temperature sensor
type
NTC temperature sensor, accurate to ±2°F (±1.2°C) at 70°F (21°C)
Wire size 16 AWG (100 ft [30.5 m] maximum) to 24 AWG (36 ft [11 m]
maximum)
Heat mode 45°F to 90°F (7°C to 32°C)Temperature
adjustment
range
Cool mode 60°F to 95°F (15°C to 35°C)
Local
temperature
sensor
±1°F (±0.6°C)
Remote
temperature
sensor
±2°F (±1.2°C) at 70°F (21°C)
Accuracy
Remote pipe
sensor
±5°F (±3.0°C)
Deadband 2°F to 5°F (1°C to 3°C)
Operating 14°F to 122°F (-10°C to 50°C); 5% RH to 90% RH, noncondensingAmbient
conditions
Storage -4°F to 140°F (-20°C to 60°C); 5% RH to 90% RH, noncondensing
Disconnection means Type 1B
Pollution degree 2
Rated impulse voltage 330 V
Automatic Action 100,000 cycles
Ratings for supply and loading 20 VAC to 30 VAC
FCP Non-Programmable and Programmable Fan Coil or PTAC Thermostat Largo User Guide26
