Johnson Controls GH-5000 User Manual

130 4280 010 E
Code Key
Flange
Size
Product Code
Number
(Excluding
Voltage)*
Actuator
Configuration
Max.
Operating
Pressure
(mbar)
Opening
Time
(s)
Stroke
(mm)
GH-5120-11_0 On-Off
GH-5120-13_1 On-Low-Off
GH-5129-14_1 On-Low-Off + CPI
GH-5120-15_1 Ignition On-Low-Off
GH-5129-16_0 On-Off + CPI
DN 40
GH-5129-19_0 On-Off + CPI + MR
1,000 <
6.5 14
GH-5220-21_0 On-Off
GH-5220-23_1 On-Low-Off
GH-5229-24_1 On-Low-Off + CPI
GH-5220-25_1 Ignition On-Low-Off
GH-5229-26_0 On-Off + CPI
DN 50
GH-5229-29_0 On-Off + CPI + MR
1,000 <
8 22
GH-5620-31_1 On-Off
GH-5620-33_1 On-Low-Off
GH-5629-34_1 On-Low-Off + CPI
GH-5620-35_1 Ignition On-Low-Off
GH-5629-36_1 On-Off + CPI
DN 65
GH-5629-39_1 On-Off + CPI + MR
1,000 <
8 22
GH-5620-41_1 On-Off
GH-5620-43_1 On-Low-Off
GH-5629-44_1 On-Low-Off + CPI
GH-5620-45_1 Ignition On-Low-Off
GH-5629-46_1 On-Off + CPI
DN 80
GH-5629-49_1 On-Off + CPI + MR
800 <
8 22
GH-5720-51_0 On-Off
GH-5720-53_1 On-Low-Off
GH-5729-54_1 On-Low-Off + CPI
GH-5720-55_1 Ignition On-Low-Off
GH-5720-56_0 On-Off + CPI
DN 100
**
GH-5729-59_0 On-Off + CPI + MR
800 < 13 36
GH-5720-61_0 On-Off
GH-5720-63_1 On-Low-Off
GH-5729-64_1 On-Low-Off + CPI
GH-5720-65_1 Ignition On-Low-Off
GH-5729-66_0 On-Off + CPI
DN 125
**
GH-5729-69_0 On-Off + CPI + MR
650 <
13 36
GH-5720-71_0 On-Off
GH-5720-73_1 On-Low-Off
GH-5729-74_1 On-Low-Off + CPI
GH-5720-75_1 Ignition On-Low-Off
GH-5729-76_0 On-Off + CPI
DN 150
**
GH-5729-79_0 On-Off + CPI + MR
350 <
13 36
* Complete Product Code Number by inserting a 1 or 3 for the blank number.
1 = 230 VAC (50/60 Hz) models and 3 = 120 VAC (50/60 Hz) models.
** Material of valve body EN-GJS-400, DIN EN 1563
CPI = Closed Position Indicator
MR = with switch for manual restart
Page:4
