Johnson Controls GVC Series User Manual

Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
110
BACnet
Attributes
Object
Type
Object
ID
Read/
Write
Short Description
Long
Description
Point Denitions (Units)
COMP2-A MV 29640 R COMP2-A
Compressor
Safety Chain 2
Displays the status of CKT 2 safety
chain 0 = normal 1 = alarm
COMP1-LO MV 29643 R COMP1-LO
Compressor
Safety Chain
Lockout 1
Displays the status of CKT 1 safety
chain lockout
0 = normal 1 = lockout
COMP2-LO MV 29644 R COMP2-LO
Compressor
Safety Chain
Lockout 2
Displays the status of CKT 2 safety
chain lockout
0 = normal 1 = lockout
LPS1 MV 29647 R LPS1
Low Pressure
Safety 1
Displays the low pressure system 1
safety alarm 0 = normal 1 = alarm
LPS2 MV 29648 R LPS2
Low Pressure
Safety 2
Displays the low pressure system 2
safety alarm 0 = normal 1 = alarm
LPS1-LO MV 29651 R LPS1-LO
Low Pressure
Lockout 1
Displays the low pressure system 1
safety lockout
0 = normal 1 = lockout
LPS2-LO MV 29652 R LPS2-LO
Low Pressure
Lockout 2
Displays the low pressure system 2
safety lockout
0 = normal 1 = lockout
Htg-En MV 29707 R/W Htg-En
Heating Mode
Enabled For
Operation
A BAS command that allows the unit
to be placed in a heating mode
0 = OFF 1 = ON
Htg-S MV 29708 R Htg-S Heating Status
Displays the active heating status
0 = OFF/idle
1 = ON
2 = SAT tempering
3 = morning warm-up
FSHW MV 29712 R Water FS
Low Temp Water
Coil Freeze Stat
Displays the status of low
temperature water coil freezestat
0 = normal 1 = alarm
HtgUnocc-En MV 29724 R/W HtgUnocc-En
Unoccupied
Heating Enabled
A BAS command to enable UNOCC
heating 0 = NO 1 = YES
VAV Box MV 29727 R VAV Box
MZ VAV Box Heat
Command
Displays the command of MZVAV
box heat 0 = OFF 1 = ON
H1 MV 29732 R H1
Heating Stage
Command 1
Displays the command of heating
stage 1 0 = OFF 1 = ON
H2 MV 29733 R H2
Heating Stage
Command 2
Displays the command of heating
stage 2 0 = OFF 1 = ON
H3 MV 29734 R H3
Heating Stage
Command 3
Displays the command of heating
stage 3 0 = OFF 1 = ON
H1-S MV 29735 R H1-S
Heating Stage 1
Status
Displays the status of heating stage 1
0 = OFF/idle
1 = ON/minimum runtime timer
2 = ON/normal command
3 = OFF/heating is disabled
H2-S MV 29736 R H2-S
Heating Stage 2
Status
Displays the status of heating stage 2
0 = OFF/idle
1 = ON/minimum runtime timer
2 = ON/normal command
3 = OFF/heating is disabled
Table 32: BACnet Points List (Continued)
