Johnson Controls
Start-Up & Operation Guide | 5586996-JSG-A-0120
67
Operation
Table 26: Menus and Submenus (Continued)
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Summary
(Figure 27)
Sensors >
Sensors
IAQSrc (Indoor Air Quality Source)
Unreliable, Local Input, Network Sensor, High
Priority, BAS Override, Input Not Available
OAQ (Outdoor Air Quality Input) ppm
SafetyCmdSrc (Safety Command
Source)
Unreliable, Local Input, Network Sensor, High
Priority, BAS Override, Input Not Available
DAH (Discharge Air Humidity) %RH
MAT (Mixed Air Temperature) deg F
BldgPres (Building Static Pressure) iwg
DA-P (Discharge Air Static Pressure) iwg
UnitEn (Unit Enable, Default- Enable) Shutdown, Enable
SenCal-Alarm (Sensor Calibration
Alarm) / Normal
Normal, Alarm
Humidistat OFF, ON
Unit
Name (Unit Name)
Serial# (Unit Serial Number)
ModelName
Unit-S (Unit Status)
Idle, SD Alarm, Purge Command, Start-Up
Wizard, Morning Warm-Up, Air Tempering,
Dehumidication, Heating, Cooling, Economizer,
Fan Only, Comfort Ventilation, Start-Up Delay,
Disabled, Updating Software
UnitEn (Unit Enable) / Enable Shutdown, Enable
HdwrReset (Hardware Reset) / No No, Yes
ResetLO (Reset Lockouts) / OFF OFF, ON
Commission
(Figure 28)
Standard
OccMode (Occupancy Mode) / Schedule Schedule, External
Tstat-Only (Thermostat Only Control
Enabled)
No, Yes
Clg-En (Cooling Mode Enabled for
Operation)
No, Yes
#ClgStgs (Number of Cooling Stages
Installed)
Htg-En (Heating Mode Enabled for
Operation)
No, Yes
#Htgstgs (Number Of Heating Stages
Installed)
stages (0–8)
Econ-En (Economizer Enabled For
Operation)
No, Yes
Econ-MinPos (Economizer Minimum
Position Setpoint)
% (0–100)
LowSpeedFan-MinPos (Economizer
Damper Minimum Position Low Speed
Fan) / 25%
% (0–100)
HighSpeedFan-MinPos (Economizer
Damper Minimum Position High Speed
Fan) / 5%
% (0–100)
SZVAVEn (SZVAV Enabled, Set by
Factory)
OFF, ON
To Next Page
