Page #86 background image
Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
86
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Details
(Figure 31)
Exhaust >
Service
EF-O (Exhaust Fan VFD % Command) %
ExF-RunTim hours
ExFanVFDFlt (Exhaust Fan VFD Fault) Normal, Alarm
EA-VP (Exhaust Air Differential Pressure) iwg
RF > Setup
RF-En (Return Fan Installed) False, True
RFHighP-SP (Return Fan Pressure High
Setpoint)
iwg (0–5)
RFLowP-SP (Return Fan Pressure Low
Setpoint)
iwg (0–5)
Bldg-Sp (Building Pressure Setpoint) iwg (-0.25 to 0.25)
RF > Service
EF-Flow (Exhaust Flow Value) cfm
BLDG-P (Building Static Pressure) iwg
RF-O (Return Fan VFD % Command) %
RF > Service
EAD-O (Exhaust Damper % Command) %
RF-C (Return Fan Command) OFF, ON
RA-VP (Return Air Differential Pressure) iwg
MZ VAV >
Setup
DctPrs-Sp (Duct Pressure Setpoint) iwg (0–5)
DctShutdownSp (Duct Pressure
Shutdown Setpoint)
iwg (0–5)
DAP-Min (Discharge Air Static Pressure
Minimum)
iwg (0.01–1)
DAP-AlmDly (Discharge Air Static
Pressure Alarm Delay)
seconds (0–600)
MZ VAV >
Service
SF-O (Fan % Command) %
DA-P (Discharge Air Static Pressure) in wc
DctPrs-Sp (Duct Pressure Setpoint) in wc (0-5)
DAT (Discharge Air Temperature) deg F
StgClgCmd (Staged Cooling Command) %
Clg-S (Cooling Status)
OFF-Idle, Thermostat Cooling, Unoccupied
Cooling, Occupied Cooling, OFF-OAT Lockout,
OFF-Disabled, OFF-Lockout, OFF-Low Supply
Voltage, OFF-Low Ambient, OFF-Low Ambient Pre-
Run Delay, OFF-Waiting For Changeover Delay,
OFF-Free Cooling, Comfort Ventilation
Econ-Free (Econ Free Cooling Available) No, Yes
C1A (Compressor 1A Command) OFF, ON
C1B (Compressor 1B Command) OFF, ON
C2A (Compressor 2A Command) OFF, ON
C2B (Compressor 2B Command) OFF, ON
OprHtgDAT-SP (Operating Heating
Discharge Air Temperature Setpoint)
deg F
StgHtgCmd (Staged Heating Command) %
OprZT (Operational Zone Temperature) deg F
Table 26: Menus and Submenus (Continued)
