Johnson Controls GVC Series User Manual

Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
88
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Details
(Figure 31)
Humidity >
Setup
HGRUnoccHum-SP (HGRH Unoccupied
Humidity Setpoint)
% (0–100)
SatisedDehum (Dehumidify In Satised) False, True
Hum-En (Humidication Enabled) Disable, Enable
Hum-SP (Humidication Setpoint) %RH (0–100)
UnoccHum-En (Humidify in Unoccupied) Disable, Enable
DAH-Sp (Discharge Air Humidity
Setpoint)
%RH (0–85)
SatisedHum (Humidify In Satised) False, True
HumidistatMode None, Humidication, Dehumidication
DehumEvapLowSp (Dehum Evap Low
Setpoint)
deg F
Cooling Discharge Air Temperature
Lower Setpoint
deg F
Humidity >
Service
HGR-S (Hot Gas Reheat Status) / OFF-
Idle
OFF - Idle, ON-Normal Command, ON-Alternate
Operation Command, OFF-Disabled
StgClgCmd (Staged Cooling Command) %
Evaporator Coil Temperature
(Evaporator Coil Temp)
deg F
OprEvapTempSp (Operational
Evaporator Temperature Setpoint)
deg F
Discharge Air Temperature deg F
OprHGRTempSp (Operational HGRH
Temperature Setpoint)
deg F
OprZT (Operational Zone Temperature) deg F
OprZH ((Operational Zone Humidity) %RH
HGR (Hot Gas Reheat Command) %
C1A (Compressor 1A Command) / OFF OFF, ON
C1B (Compressor 1B Command) / OFF OFF, ON
C2A (Compressor 2A Command) / OFF OFF, ON
C2B (Compressor 2B Command) / OFF OFF, ON
Modulating Compressor Output % (0–100)
RAH (Space Humidity RAH Input) %RH
ZAH (Zone Humidity Input) %RH
HGRB-C (Hot Gas Reheat Bleed Valve
Command) / Open
Close, Open
RAH-Alarm (Return Air Humidity Sensor
Alarm) / Normal
Normal, Alarm
Humidistat OFF, ON
ERV
HRW-S (Heat Recovery Wheel Status)
OFF, Max Cooling, Max Heating, Blocking
Protection, Heating Control, Heating Low Limit
SF-C (Supply Fan Command) OFF, ON
Econ-Free (Economizer Free Cooling
Available)
No, Yes
EAHR-T (Exhaust Air Heat Recovery
Temperature)
deg F
Table 26: Menus and Submenus (Continued)
