Johnson Controls GVC Series User Manual

Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
90
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Start-Up
Wizard
(Figure 33)
Start-Up
Wizard (Refer
to Start-
Up Wizard
Sequence on
page 26)
Start-Up Wizard Status
OFF, Enter Supply Line Voltage, OA and RA Dampers
Half Open, OA and RA to Outside Air Only, OA and
RA Damper Test Done, Exhaust Damper Half Open,
Exhaust Damper Fully Opening, Exhaust Damper
Fully Closing, Exhaust Damper Test Done, Isolation
Damper Fully Opening, Isolation Damper Fully
Closing, Isolation Damper Test Done, Heat Recovery
Dampers Open, Heat Recovery Dampers Close,
Heat Recovery Wheel On, Heat Recovery Wheel
On Max, Heat Recovery Test Done, Supply Fan on
Max, Supply Fan Duct Pressure Control, Supply
Fan Test Done, Compressor 1A Test, Compressor
1B Test, Compressor 2A Test, Compressor 2B Test,
Check Compressor 1A Oil, Check Compressor 1B Oil,
Check Compressor 2A Oil, Check Compressor 2B
Oil, Charge Check Circuit 1, Charge Check Circuit 2,
Compressor 1A Test Done, Compressor 1B Test Done,
Compressor 2A Test Done, Compressor 2B Test
Done, Unavailable for Charge Check, Enter Circuit 1
Data, Enter Circuit 2 Data, Circuit 1 Tests Done, Circuit
2 Tests Done, Compressor Tests Done, Electric Heat
1–8 Test Done, Verify Electric Heat 1–8 On, Gas Heat
1–5 Low Fire Start, Gas Heat 1–5 High Fire Start,
Verify Gas Heat 1–5 Low Fire, Verify Gas Heat 1–5
High Fire, Gas Heat Module 1–5 Test Done, Gas Heat
Module 1–5 Cool Down, Heating Tests Done
Active Test Status
Stabilize, Wait, Check, Available, Not Run, Pass,
Warning-Low DSP, Warning-SAT Not Dropped,
Warning-SAT Not Increased, Warning-BSP Not
Dropped, Warning, Fail-APS On Early, Fail-APS Off,
Fail-Low Voltage, Fail-Low DSP, Fail-HPS, Fail-FRZ,
Fail-LPS, Fail-LS, Fail-GV Off, Fail-Damper, Fail-
SAT Unreliable, Fail-VFD Fault, Fail- Fan Overload,
Fail, Fail-DSP Unreliable, Fail-BSP Unreliable
Self Test Time Remaining seconds
Self Test Time Remaining seconds
Phase A Voltage V
Phase B Voltage V
Phase C Voltage V
Supply Fan L1 Amps A
Supply Fan L2 Amps A
Supply Fan L3 Amps A
Liquid Temperature deg F (-50 to 500)
Liquid Pressure psi (-50 to 750)
Suction Temperature deg F (-50 to 500)
Suction Pressure psi (-50 to 750)
Check OK? No, Yes
Continue No, Yes
Damper Test / Disable Disable, Enable
Heat Recovery Wheel Test / Disable Disable, Enable
Supply Fan Test / Disable Disable, Enable
Compressor Test / Disable Disable, Enable
Heating Test / Disable Disable, Enable
Run Startup Wizard / No No, Yes
Cancel No, Yes
Table 26: Menus and Submenus (Continued)
