Johnson Controls Ducted Systems 13
Table 7: kW and MBH conversions - for total power input requirement
For a power distribution voltage that is different from the provided nominal voltage, multiply the kW and MBH data from Table 8 by the conversion
factor in the following table.
Distribution power (V) Nominal voltage (V) Conversion factor
208 240 0.75
220 240 0.84
230 240 0.92
Table 8: Electric heat performance data: 208/230-1-60 and 208/230-3-60
Heater
models
1,2
Nominal kW
at 240 V
Total heat
3
kW staging
kW MBH W1 only W1 and W2
208 V 230 V 208 V 230 V 208 V 230 V 208 V 230 V
Single
phase
8HK(0,1)6500206 2.4 1.8 2.2 6.2 7.5 1.8 2.2 1.8 2.2
8HK(0,1)6500506 4.8 3.6 4.4 12.3 15 3.6 4.4 3.6 4.4
8HK(0,1)6500806 7.7 5.8 7.1 19.7 24.1 5.8 7.1 5.8 7.1
8HK(0,1)6501006 9.6 7.2 8.8 24.6 30.1 7.2 8.8 7.2 8.8
8HK(1,2)6501506 14.4 10.8 13.2 36.9 45.1 3.6 4.4 10.8 13.2
8HK(1,2)6502006 19.2 14.4 17.6 49.2 60.2 7.2 8.8 14.4 17.6
8HK(1,2)6502506 24 18 22 61.5 75.2 7.2 8.8 18 22
Three
phase
8HK06501025 9.6 7.2 8.8 24.6 30.1 7.2 8.8 7.2 8.8
8HK06501525 14.4 10.8 13.2 36.9 45.1 10.8 13.2 10.8 13.2
8HK16502025 19.2 14.4 17.6 49.2 60.2 7.2 8.8 14.4 17.6
8HK16502525 24 18 22 61.5 75.2 9 11 18 22
1. (0,1) - 0 = no service disconnect or 1 = with service disconnect.
2. (1,2) - 1 = with service disconnect, no breaker jumper bar or 2 = with service disconnect and breaker jumper bar.
3. For different power distributions, see Table 7.
Table 9: Electrical data for single source power supply: 208/230-1-60
Air handler models
Heater models
1,2
Heater
amps (A)
at 240 V
Field wiring
Minimum circuit ampacity (A)
MOP
3
(A)
208 V 230 V 208 V 230 V
B18B
8HK(0,1)6500206 10 14.1 15.2 15 20
8HK(0,1)6500506 20 24.9 27.2 25 30
8HK(0,1)6500806 32 38.1 41.8 40 45
8HK(0,1)6501006 40 46.5 51.1 50 60
B24C
8HK(0,1)6500206 10 14.1 15.2 15 20
8HK(0,1)6500506 20 24.9 27.2 25 30
8HK(0,1)6500806 32 38.1 41.8 40 45
8HK(0,1)6501006 40 46.5 51.1 50 60
8HK(1,2)6501506 60 68.2 75.0 70 80
B30D
8HK(0,1)6500206 10 15.6 16.7 20 20
8HK(0,1)6500506 20 26.4 28.7 30 30
8HK(0,1)6500806 32 39.6 43.3 40 45
8HK(0,1)6501006 40 48.0 52.6 50 60
8HK(1,2)6501506 60 69.7 76.5 70 80
8HK(1,2)6502006 80 91.3 100.4 100 110
B36D
8HK(0,1)6500206 10 15.6 16.7 20 20
8HK(0,1)6500506 20 26.4 28.7 30 30
8HK(0,1)6500806 32 39.6 43.3 40 45
8HK(0,1)6501006 40 48.0 52.6 50 60
8HK(1,2)6501506 60 69.7 76.5 70 80
8HK(1,2)6502006 80 91.3 100.4 100 110
Continued on next page
