16 Johnson Controls Ducted Systems
C60H
8HK06501025 23.1 31.7 34.4 35 35
8HK06501525 34.6 44.2 48.2 45 50
8HK16502025
1
46.2 56.7 62.0 60 70
D60H
8HK06501025 23.1 31.7 34.4 35 35
8HK06501525 34.6 44.2 48.2 45 50
8HK16502025
1
46.2 56.7 62.0 60 70
8HK16502525
1
57.7 69.2 75.8 70 80
D60J
8HK06501025 23.1 31.7 34.4 35 35
8HK06501525 34.6 44.2 48.2 45 50
8HK16502025
1
46.2 56.7 62.0 60 70
8HK16502525
1
57.7 69.2 75.8 70 80
1. 0 = no service disconnect OR 1 = with service disconnect. The 20 kW and 25 kW heater models (8HK16502025 and 8HK16502525) come with service disconnects
standard. Single source power MCA and MOP requirements are given here only for reference if used with field installed single point power modification.
2. MOP = Maximum overcurrent protection device; must be HACR type circuit breaker or time delay fuse. The first circuit includes blower motor amps. Refer to the lat-
est edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
Table 11: Electrical data for single source power supply: 208/230-3-60 (continued)
Air handler models
Heater models
1
Heater
amps (A)
at 240 V
Field wiring
Minimum circuit ampacity (A)
MOP
2
(A)
208 V 230 V 208 V 230 V
Table 12: Electrical data for multi-source power supply: 208/230-3-60
Air handlers
models
Heater
models
1
Heater amps (A)
at 240V
Minimum circuit ampacity (A)
MOP
2
(A)
208V 230V 208V 230V
Circuit Circuit
First
2
Second
First
2
Second
First
2
Second
First
2
Second
B30D 8HK16502025 46.2 29.7 25.0 32.4 27.6 30 25 35 30
B36D 8HK16502025 46.2 29.7 25.0 32.4 27.6 30 25 35 30
C36D 8HK16502025 46.2 29.7 25.0 32.4 27.6 30 25 35 30
C42F 8HK16502025 46.2 29.7 25.0 32.4 27.6 30 25 35 30
C48G 8HK16502025 46.2 31.7 25.0 34.4 27.6 35 25 35 30
D48G 8HK16502025 46.2 31.7 25.0 34.4 27.6 35 25 35 30
C60H 8HK16502025 46.2 31.7 25.0 34.4 27.6 35 25 35 30
D60H
8HK16502025 46.2 31.7 25.0 34.4 27.6 35 25 35 30
8HK16502525 57.7 38.0 31.2 41.3 34.5 40 35 45 35
D60J
8HK16502025 46.2 31.7 25.0 34.4 27.6 35 25 35 30
8HK16502525 57.7 38.0 31.2 41.3 34.5 40 35 45 35
1. The 20kW and 25kW heater models (8HK06502025 and 8HK06502525) come with service disconnects standard.
2. MOP = Maximum overcurrent protection device; must be HACR type circuit breaker or time delay fuse. The first circuit includes blower motor amps. Refer to the lat-
est edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
Table 13: Airflow data (CFM per Watts)
Models
Blower
motor speed
External static pressure (in. W.C.)
Unit 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
B18B
High (5)
CFM 975 925 875 825 800 750 700 650 600 550
W 129 137 145 153 161 169 177 186 194 202
Medium high (4)
CFM 900 850 800 775 725 675 625 575 525 500
W 110 117 124 132 139 146 153 160 167 175
Medium (3)
CFM 825 775 725 700 650 600 550 500 450 400
W 94 101 107 114 120 127 134 140 147 154
Medium low (2)
CFM 650 600 550 500 425 — — — — —
W5863687378—————
Low (1)
CFM450—————————
W31—————————
Continued on next page
