Johnson Controls JHETD60J User Manual

6112628-UIM-B-0622
Johnson Controls Ducted Systems 17
B24C
High (5)
CFM 1150 1125 1100 1050 1025 975 950 900 875 850
W 190 199 209 219 229 238 248 258 267 277
Medium high (4)
CFM 1000 950 925 875 825 775 750 700 650 600
W 130 138 147 155 163 171 180 188 196 204
Medium (3)
CFM 775 725 675 625 575 525 450 400 — —
W 75 81 88 95 101 108 114 121 — —
Medium low (2)
CFM 675 600 550 500 425 — — — — —
W5561677379—————
Low (1)
CFM 525 450 — — — — — — — —
W3440————————
B30D
High (5)
CFM 1150 1125 1075 1050 1025 975 950 925 875 850
W 221 228 235 243 252 262 273 285 297 311
Medium high (4)
CFM 1000 950 900 875 825 800 750 700 675 625
W 147 156 164 172 181 189 198 206 214 223
Medium (3)
CFM 775 725 700 650 600 550 500 450 400 —
W 87 93 100 106 113 120 126 133 139 —
Medium low (2)
CFM 650 600 550 500 450 400 — — — —
W626772788389————
Low (1)
CFM 575 525 475 400 — — — — — —
W49545965——————
B36D
High (5)
CFM 1500 1475 1450 1425 1425 1400 1375 1350 1325 —
W 482 493 504 516 527 539 550 562 573 —
Medium high (4)
CFM 1325 1300 1275 1250 1225 1200 1175 1150 1125 1100
W 332 339 347 357 367 379 391 405 420 435
Medium (3)
CFM 975 950 900 875 825 800 750 700 675 625
W 145 154 162 170 178 186 194 202 210 219
Medium low (2)
CFM 925 875 825 800 750 700 675 625 575 550
W 121 128 136 143 151 158 166 173 180 188
Low (1)
CFM 650 600 550 500 450 400 — — — —
W606571768187————
C36D
High (5)
CFM 1600 1575 1525 1500 1450 1425 1400 1350 1325 1275
W 377 391 405 419 434 448 462 476 490 504
Medium high (4)
CFM 1400 1375 1325 1275 1225 1200 1150 1100 1075 1025
W 260 272 283 294 305 316 328 339 350 361
Medium (3)
CFM 1100 1050 1000 950 900 850 800 725 675 625
W 143 152 161 169 178 187 195 204 212 221
Medium low (2)
CFM 950 900 825 775 725 650 600 550 475 425
W 103 110 117 124 131 138 146 153 160 167
Low (1)
CFM 725 650 575 525 450 375 — — — —
W606672778389————
C42F
High (5)
CFM 1525 1500 1450 1425 1375 1350 1300 1275 1225 1200
W 334 348 363 377 391 405 419 433 448 462
Medium high (4)
CFM 1375 1325 1300 1250 1200 1150 1125 1075 1025 975
W 247 259 270 282 293 305 317 328 340 352
Medium (3)
CFM 1050 1000 950 900 850 775 725 675 625 575
W 130 138 146 155 163 171 180 188 197 205
Medium low (2)
CFM 925 875 800 750 700 625 575 525 450 400
W 97 104 112 119 126 133 141 148 155 162
Low (1)
CFM 700 625 575 500 425 — — — — —
W5661677378—————
Continued on next page
Table 13: Airflow data (CFM per Watts) (continued)
Models
Blower
motor speed
External static pressure (in. W.C.)
Unit 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
