Figure 19: Location of coil trapped and plugged drain connections
A1698-001
Upflow application Downflow application
Blower
section
Right flow application
Left flow application
Coil section
Drain plug for
primary drain
Drain plug for
primary drain
Primary drain
trap connection
Primary drain
trap connection
Drain plug for
horizontal drain
Drain plug for
horizontal drain
Horizontal drain
trap connection
Horizontal drain
trap connection
Coil section
Coil
section
Coil
section
Blower
section
Blower
section
Blower
section
