Johnson Controls JMET Series User Manual

6139716-UIM-A-0422
12 Johnson Controls Ducted Systems
Notes:
• No electric heat installed
• Air handler units are tested to UL60335-2-40 standards up to 0.6 in. W.C. external static pressure.
• Dry coil conditions only; tested without filters
• For optimal performance, external static pressures of 0.2 in. W.C. to 0.5 in. W.C. are recommended. Heating applications are tested at 0.5 in.
W.C. external static pressure.
• Airflow data shown is from testing performed at 230 V. JMET units use a standard ECM constant torque motor and there is minimal variation of
airflow at other distribution voltage values. The above data can be used for airflow at other distribution voltages.
Table 14: Airflow data (CFM per Watts)
Models
Blower
motor speed
External static pressure (in. W.C.)
Unit 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
JMET08B
High (5)
CFM 1100 1050 1000 925 875 825 775 725 675 600
W 113 122 131 140 149 158 167 176 185 194
Medium high (4)
CFM 1025 975 900 850 800 750 675 625 575 500
W 95 104 112 120 129 137 145 154 162 171
Medium (3)
CFM 925 875 800 750 700 625 575 500 450 400
W 78 85 93 100 108 115 123 130 138 145
Medium low (2)
CFM 850 775 725 650 575 525 450 — — —
W637077839096103———
Low (1)
CFM 575 500 425 — — — — — — —
W32 38 44 — — — — —— —
JMET12B
High (5)
CFM 1300 1250 1225 1175 1125 1075 1025 1000 950 900
W 177 184 192 201 212 223 235 249 263 279
Medium high (4)
CFM 1475 1425 1400 1375 1325 1300 1250 1225 1200 1150
W 259 266 275 285 296 308 322 336 351 367
Medium (3)
CFM 1150 1075 1025 975 925 875 800 750 700 650
W 118 129 139 150 160 171 181 192 202 213
Medium low (2)
CFM 1025 975 900 850 800 725 675 625 550 500
W 94 103 113 122 132 141 151 160 170 179
Low (1)
CFM 750 675 600 525 450 400 — — — —
W515764707784————
JMET12C
High (5)
CFM 1675 1650 1625 1575 1550 1525 1475 1425 1375 1325
W 294 303 314 326 339 353 369 386 404 424
Medium high (4)
CFM 1500 1475 1450 1400 1375 1325 1250 1200 1125 1050
W 216 225 235 247 259 273 288 304 322 341
Medium (3)
CFM 1350 1325 1275 1225 1175 1100 1025 975 900 800
W 153 165 178 190 203 216 228 241 253 266
Medium low (2)
CFM 1075 1000 925 850 775 700 625 550 475 425
W 87 96 105 114 123 131 140 149 158 167
Low (1)
CFM 950 875 800 725 650 575 500 425 — —
W 67 78 88 97 105 113 120 127 — —
JMET16C
High (5)
CFM 2075 2050 2000 1975 1950 1925 1900 1875 1850 1825
W 501 516 531 546 560 575 590 605 620 634
Medium high (4)
CFM 1875 1850 1825 1775 1750 1725 1675 1650 1625 1600
W 374 388 402 415 429 443 456 470 484 497
Medium (3)
CFM 1500 1475 1425 1400 1350 1300 1250 1175 1100 1025
W 197 210 223 236 249 262 276 289 302 315
Medium low (2)
CFM 1325 1250 1200 1125 1075 1000 950 875 800 750
W 132 144 155 166 178 189 200 212 223 234
Low (1)
CFM 1050 975 900 825 750 650 575 500 425 —
W 79 88 96 105 114 122 131 140 148 —
JMET18D
High (5)
CFM 2250 2225 2200 2175 2125 2100 2075 2050 2025 2000
W 595 606 618 633 648 666 685 705 727 751
Medium high (4)
CFM 2075 2050 2000 1975 1950 1900 1875 1850 1800 1775
W 444 460 475 491 506 522 537 553 568 584
Medium (3)
CFM 1875 1850 1800 1775 1725 1700 1650 1625 1575 1525
W 329 344 359 374 389 404 419 434 449 463
Medium low (2)
CFM 1450 1400 1325 1250 1200 1125 1050 1000 925 850
W 153 166 179 192 206 219 232 245 258 271
Low (1)
CFM 1300 1225 1150 1075 1000 925 850 800 725 650
W 120 131 143 154 166 178 189 201 212 224
