FORM 145.05-EG2 (618)
JOHNSON CONTROLS
21
TABLE 7 - REFRIGERANT CHARGE DATA – LSWU060-LSWU105
MODEL #
COMP A COMP B COMP C COMP D COMP E COMP F
NORM
HP
410A
CHARGE-
LBS
NORM
HP
410A
CHARGE-
LBS
NORM
HP
410A
CHARGE-
LBS
NORM
HP
410A
CHARGE-
LBS
NORM
HP
410A
CHARGE-
LBS
NORM
HP
410A
CHARGE-
LBS
LSWU025 10 20.0 10 20.0 - - - - - - - -
LSWU032 15 21.5 11 21.5 - - - - - - - -
LSWU035 15 23.0 13 23.0 - - - - - - - -
LSWU040 15 27.0 15 27.0 - - - - - - - -
LSWU050 15 28.5 11 25.0 11 25.0 - - - - - -
LSWU060 15 26.5 15 26.5 15 27.5 - - - - - -
LSWU070 15 22.5 15 22.5 15 22.50 15 22.5 - - - -
LSWU080 15 23.25 15 23.25 15 25.3 15 25.3 - - - -
LSWU095 13 19.0 13 19.0 13 23.50 13 23.5 13 23.5 13 23.5
LSWU105 15 19.0 15 19.0 15 23.50 15 23.5 15 27.5 15 27.5
