Johnson Controls L-Series User Manual

FORM 145.05-EG2 (618)
JOHNSON CONTROLS
63
Supply Fan Data
LSWU025–040
TABLE 21 - COMEFRI 25” FAN: LSWU025–040
CFM
TOTAL STATIC PRESSURE (INCHES OF WATER COLUMN)
2.0 3.0 4.0 5.0 6.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
4,000 819 1.58 818.8 1.6 818.8 1.6 818.8 1.6 818.8 1.6
6,000 1002.7 3.1 1168.7 4.7 1228.2 5.3 1228.2 5.3 1228.2 5.3
8,000 1124.3 4.5 1264.2 6.4 1393.7 8.3 1517.7 10.4 1637.6 12.6
10,000 1268.3 6.4 1390.6 8.6 1505.1 10.8 1613.4 13.2 1716.7 15.6
12,000 1428.5 8.9 1534.3 11.4 1636.7 14.0 1734.7 16.6 1828.3 19.4
14,000 1601.9 12.3 1691.4 14.9 1782.7 17.8 1870.6 20.8 1957.0 23.9
TABLE 22 - COMEFRI 28” FAN: LSWU035–040
CFM
TOTAL STATIC PRESSURE (INCHES OF WATER COLUMN)
2.0 3.0 4.0 5.0 6.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
8,000 906 4.31 1044.6 6.3 1177.3 8.6 1216.0 9.3 1216.0 9.3
10,000 993.8 5.8 1118.2 8.1 1231.5 10.5 1339.3 13.1 1444.5 16.0
12,000 1095.3 7.7 1205.6 10.4 1309.7 13.1 1407.2 16.0 1499.6 18.9
14,000 1207.1 10.2 1305.0 13.1 1398.8 16.2 1489.2 19.4 1575.7 22.7
16,000 1327.6 13.3 1413.4 16.5 1498.2 19.9 1580.3 23.4 1660.7 27.0
18,000 1454.2 17.1 1528.5 20.5 1605.6 24.2 1680.8 28.0 Consult Factory
LSWU050–060
TABLE 23 - COMEFRI 32” FAN: LSWU050–060
CFM
TOTAL STATIC PRESSURE (INCHES OF WATER COLUMN)
2.0 3.0 4.0 5.0 6.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
12,000 1095 7.72 1205.6 10.4 1309.7 13.1 1407.2 16.0 1499.6 18.9
14,000 1207.1 10.2 1305.0 13.1 1398.8 16.2 1489.2 19.4 1575.7 22.7
16,000 1327.6 13.3 1413.4 16.5 1498.2 19.9 1580.3 23.4 1660.7 27.0
18,000 1454.2 17.1 1528.5 20.5 1605.6 24.2 1680.8 28.0 Consult Factory
20,000 1583.4 21.8 1651.3 25.4 Consult Factory Consult Factory Consult Factory
TABLE 24 - COMEFRI 36” FAN: LSWU050–060
CFM
TOTAL STATIC PRESSURE (INCHES OF WATER COLUMN)
2.0 3.0 4.0 5.0 6.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
14,000 753 7.36 859.5 10.6 957.5 14.0 1044.8 17.5 1044.8 17.5
16,000 796.6 8.8 898.8 12.4 989.5 16.1 1075.2 20.0 1160.7 24.2
18,000 844.0 10.4 940.9 14.4 1028.3 18.5 1108.3 22.7 1184.9 27.0
20,000 895.8 12.3 984.9 16.6 1069.6 21.1 1147.1 25.7 1219.3 30.3
22,000 950.8 14.5 1032.6 19.1 1112.5 23.9 1188.2 28.9 1258.5 33.9
24,000 1008.5 17.1 1083.9 21.8 1158.5 27.0 1231.0 32.3 1299.4 37.8
