FORM 145.05-EG2 (618)
64
JOHNSON CONTROLS
LSWU070–105
TABLE 25 - TWIN CITY 36” FAN: LSWU070–105
CFM
TOTAL STATIC PRESSURE (INCHES OF WATER COLUMN)
2.0 3.0 4.0 5.0 6.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
16,000 822.1 7.2 921.4 10.3 1015.1 13.6 1107.5 17.4 1195.8 21.4
18,000 875.4 8.5 967.6 11.9 1053.3 15.3 1136.8 19.1 1219.0 23.3
20,000 931.8 10.0 1017.1 13.7 1098.8 17.4 1174.9 21.3 1250.2 25.5
22,000 990.4 11.7 1070.9 15.6 1146.9 19.7 1220.1 23.9 1289.1 28.1
24,000 1050.1 13.6 1127.2 17.8 1197.9 22.2 1267.6 26.7 1334.3 31.2
26,000 1110.8 15.7 1185.0 20.3 1253.2 24.9 1317.7 29.7 1381.5 34.6
28,000 1172.6 18.0 1244.3 22.9 1309.7 27.9 1371.4 32.9 1431.2 38.1
30,000 1235.5 20.5 1304.4 25.8 1367.6 31.2 1427.3 36.5 Consult Factory
32,000 1299.6 23.3 1365.3 29.0 1426.9 34.7 Consult Factory Consult Factory
34,000 1364.6 26.5 1427.0 32.5 Consult Factory Consult Factory Consult Factory
TABLE 26 - TWIN CITY 40” FAN: LSWU095–105
CFM
TOTAL STATIC PRESSURE (INCHES OF WATER COLUMN)
2.0 3.0 4.0 5.0 6.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
16,000 735.8 7.8 846.7 12.3 943.4 16.9 1037.9 21.7 1066.7 23.3
18,000 770.3 8.5 875.4 13.5 971.4 18.6 1056.1 23.7 1140.2 29.1
20,000 806.7 9.3 908.2 14.6 998.1 20.1 1084.4 25.9 1160.3 31.5
22,000 845.6 10.0 942.8 15.7 1030.4 21.6 1110.6 27.7 1189.1 34.2
24,000 883.7 10.7 977.8 16.7 1064.8 23.2 1142.6 29.7 1215.2 36.3
26,000 922.8 11.4 1017.8 17.9 1097.9 24.5 1175.7 31.6 1247.0 38.7
28,000 962.9 12.4 1055.6 18.9 1134.9 25.9 1210.6 33.5 1279.4 40.9
30,000 1004.2 13.7 1094.1 19.9 1174.8 27.6 1243.1 34.9 1314.7 43.3
32,000 1046.5 15.3 1133.3 21.0 1212.6 28.9 1283.2 37.0 1347.1 45.1
34,000 1089.8 17.5 1173.4 22.5 1250.9 30.2 1322.2 38.9 Consult Factory
36,000 1134.2 20.2 1214.4 24.3 1289.9 31.6 Consult Factory Consult Factory
Supply Fan Data (Cont’d)
