Johnson Controls L-Series User Manual

FORM 145.05-EG2 (618)
44
JOHNSON CONTROLS
PLENUM OPTIONS
LSWU050–060 MODELS
72.88
65.25
31.23
9.25
1.37
NOTE: OPTIONAL HOT WATER PIPING WIL
L
BE INSIDE FULL PLENUM
RIGHT
FRONT
REARLEFT
OPTIONAL FULL PLENUM
FIELD-CUT OPENING IS STANDARD;
OPTIONAL
FACTORY-CUT OPENINGS
ARE AVAILABLE ON FOUR SIDES
38.25
89.25
31.23
9.25
1.37
RIGHT
FRONT
REAR
LEFT
OPTIONAL HALF PLENUM
(POSITIONED OVER FAN SECTION ONLY)
FIELD-CUT OPENING IS STANDARD;
OPTIONAL FACTORY-CUT OPENINGS
ARE AVAILABLE
ON FRONT & REAR SIDES ONLY
NOTES:
SOUND-ATTENUATING PLENUM OPTION CAN BE COMBINED1.
WITH ANY FILTER SECTION OPTION.
SOUND-ATTENUATING PLENUM SHIPS SEPARATELY FROM2.
BASE UNIT SEGMENT(S).
OPTION IS NOT AVAILABLE WITH DUCTED CONNECTIONS3.
WITH THIS OPTION THE TOP ROW OF FILTERS CAN ONLY BE4.
REMOVED FROM THE END OF THE FILTER RACK.
NO.
FILTER OPTIONS
"A"
1
2
4" FILTER 82.00
4" PRE-FILTER + 4" HIGH EFFICIENCY FILTER 86.25
"A"
23.91
7.86
85.59
89.88
27.94
OPTIONAL
SOUND-ATTENUATING (INLET) PLENUM
NOTES:
SOUND-ATTENUATING PLENUM OPTION CAN BE COMBINED1.
WITH ANY FILTER SECTION OPTION.
SOUND-ATTENUATING PLENUM SHIPS SEPARATELY FROM2.
BASE UNIT SEGMENT(S).
OPTION IS NOT AVAILABLE WITH DUCTED CONNECTIONS3.
WITH THIS OPTION THE TOP ROW OF FILTERS CAN ONLY BE4.
REMOVED FROM THE END OF THE FILTER RACK.
NO.
FILTER OPTIONS
"A"
1
2
4" FILTER 82.00
4" PRE-FILTER + 4" HIGH EFFICIENCY FILTER 86.25
"A"
23.91
7.86
85.59
89.88
27.94
OPTIONAL SOUND-ATTENUATING (INLET) PLENUM
Dimensional Data (Cont’d)
