FORM 145.05-EG2 (618)
70
JOHNSON CONTROLS
Operating Weights (Cont’d)
TABLE 31 - OPERATING WEIGHTS (LBS) - LSWU070–105
MODEL LSWU070 LWSU080 LSWU095 LSWU105
Compressor Section
H2O
Weight
H2O
Weight
H2O
Weight
H2O
Weight
Compressor-Standard 4316 231 4456 231 5331 231 5442 231
Compressor-High Efciency 4376 231 4542 231 5441 231 5562 231
Water Economy Coil 783 240 989 240 1036 240 1036 240
Hot Water Heat 288 70 320 70 320 70 320 70
Fan Section
Supply Fan 2040 2040 2040 2040
36 Inch Class II 685 685 685 685
40 Inch Class II 920 920 920 920
40 Inch Class III 1065 1065 1065 1065
Supply Fan Motor
ODP Prem Eff Prem Eff Prem Eff Prem Eff
15HP 327 327 327 327
20HP 367 367 367 367
25HP 470 470 470 470
30HP 512 512 512 512
40HP 614 614 614 614
50HP 622 622 622 622
TEFC Prem Eff Prem Eff Prem Eff Prem Eff
15HP 365 365 365 365
20HP 421 421 421 421
25HP 538 538 538 538
30HP 573 573 573 573
40HP 742 742 742 742
50HP 900 900 900 900
Variable Frequency Drive (VFD)
Variable Air Volume (VAV) & VAV w/ Bypass
15HP 96 96 96 96
20HP 96 96 96 96
25HP 115 115 115 115
30HP 115 115 115 115
40HP 115 115 115 115
50HP 190 190 190 190
Filter Section
4" 30-35% Efciency (MERV 8) 257 257 257 257
4" 80–85% Efciency +
4" 30–35% Efciency Prelter (MERV 13 + 8)
487 487 487 487
Plenums
Inlet Plenum - Sound Attenuating 439 439 439 439
Outlet Plenum - Half 415 415 415 415
Outlet Plenum - Full 556 556 556 556
Inlet Plenum - Air Economy 1540 1540 1540 1540
Electric Heat Section
Fan 161 161 161 161
**Weights shown represent approximate operating weights, and they have a ±10% accuracy.
