LN Series Free Programmable LN-PRGxxx-12 Controllers Installation Instructions18
Outputs Digital (Triac) Outputs: 5
Universal Outputs: 3
Digital:
24 VAC Triac, digital (on/off), floating, or PWM; software configurable
0.5 A continuous
1.0 A at 15% duty cycle for a 10-minute period
PWM control: adjustable period from 2 seconds to 65 seconds
Floating control: requires two consecutive outputs
minimum plus on/off: 500 milliseconds
adjustable drive time period
External power supply
Universal:
Linear (0-10 VDC)
Digital (on/off), PWM, or floating (0 to 12 VDC); software configurable; built-in snubbing
diode to protect against back EMF, for example when used with a 12 VDC relay.
PWM control: adjustable period from 2 seconds to 65 seconds
Floating control:
minimum plus on/off: 500 ms
adjustable drive time period
60 mA maximum at 12 VDC (60
°C [140°F])
minimum resistance 200 ohms
Auto reset fuse
60 mA at 60
°C (140°F)
100 mA at 20
°C (68°F)
Output Resolution: 10-bit digital/analog converter
Wireless Receiver
1
Communication: EnOcean® Wireless standard
Number of Wireless Inputs
2
: 24
Supported Wireless Receivers: LN-WMOD315-0 and LN-WMOD868-0
Telephone Cord Cable: Connector: 4P4C modular jack, Length: 6.5 ft (2 m)
Electromagnetic Compatibility CE Emission: EN61000-6-3: 2007 Generic standards for residential, commercial, and
light-industrial environments (pending).
CE Immunity: EN61000-6-1: 2007; Generic standards for residential, commercial, and
light-industrial environments (pending).
FCC: This device complies with FCC rules part 15, subpart B, class B (pending)
LN Series Communicating
Sensor
Communication: RS-485
Number of sensors per controller: up to 4, in daisy-chain configuration
Cable: Cat 5e, 8 conductor twisted pair
Connector: RJ-45
Agency Compliance United States:
Under UL 916, Energy Management Equipment
Material
3
: UL94-5VA
Canada:
Under UL 916, Energy Management Equipment
Material
3
: UL94-5VA
Europe: CE Mark – Johnson Controls, Inc., declares that the products are in compliance
with the essential requirements and other relevant provisions of the EMC Directive
2004/108/EC.
1. Available when an optional external Wireless Receiver is connected to the controller. Some wireless inputs may use more
than one wireless input from the controller.
2. Some wireless modules may use more than one wireless input from the controller.
3. All materials and manufacturing processes comply with the RoHS directive and are marked according to the Waste
Electrical and Electronic Equipment (WEEE) directive.
LN-PRG203-12 (Part 2 of 2)
