LN Series Free Programmable LN-PRGxxx-12 Controllers Installation Instructions 19
LN-PRG300-12 (Part 1 of 2)
Product Code LN-PRG300-12
Power Requirements Voltage: 24 VAC/DC; ±15%, 50/60 Hz, Class 2
Protection: 3.0 A user-replaceable fuse
Power Consumption: 16 VA typical plus all output loads
Maximum Consumption: 38 VA
Environmental Operating Temperature: 0 to 50
°C, (32 to 122°F)
Storage Temperature: -20 to 50
°C, (-4 to 122°F)
Relative Humidity: 0 to 90%
General Processor: STM32 (ARM Cortex™ M3) MCU, 32 bit
Processor Speed: 72 MHz
Memory: 1 MB Nonvolatile Flash (applications), 2 MB Nonvolatile Flash (storage)
96 kB RAM
Media Channel: TP/FT-10; 78 Kbps
Communication: LonTalk® protocol
Transceiver: FT 5000 Free Topology Smart Transceiver
Status Indicator: Green LED - power status and LON TX, Orange LED - service
and LON RX
Communication Jack: LON® mono audio jack
L
ONMARK® Interoperability: Version 3.4
Device Class: Static Programmable Device
L
ONMARK Functional Profile (pending): Input Objects: Open-Loop Sensor #1,
Output Objects: Open - Loop Sensor #3, Node Object: #0, Real Time Clock: Real Time
Keeper #3300, Scheduler: Scheduler #20020, Calendar: Calendar #20030,
Programmable Device: Static Programmable Device #410
Enclosure Material: FR/ABS
Dimensions (with screws): 5.7 x 4.7 x 2.0 in. (144.8 x 119.4 x 50.8 mm)
Shipping Weight: 0.97 lb (0.44 kg)
Inputs Number of Inputs: 10
LN Series Communicating Sensors: 12
Input Types: universal software configurable
Voltage: 0 to 10 VDC (40k ohm input impedance)
0 to 5 VDC (high input impedance)
Current: 0 to 20 mA with 249 ohmjumper configurable internal resistor
Digital: dry contact
Pulse: UI1 to UI4; 50 Hz maximum; Minimum 10 ms On/10 ms Off, SO output
compatible; UI5 to UI10: 1 Hz maximum; Minimum 500 ms On/500 ms Off, dry contact
Resistor Support: 0 to 350k ohms. All thermistor types that operate within this range are
supported. The following temperature sensors are pre-configured:
Thermistor:
Type 2 and Type 3 10k ohm (10k ohm at 25
°C [77°F])
Platinum:
PT1000 1k ohm (1k ohm at 0°C [32°F])
Nickel:
RTD Ni1000 (1k ohm at 0°C [32°F])
RTD Ni1000 (1k ohm at 21°C [69.8°F])
Input Resolution: 16-bit analog/digital converter
Power Supply Output: 15 VDC; maximum 200 mA (10 inputs x 20 mA each)
