LN Series Free Programmable LN-PRGxxx-12 Controllers Installation Instructions20
Outputs Universal Outputs: 8
Universal Output Characteristics:
0-10 VDC linear; digital 0 to12 VDC (on/off), PWM, or floating (0 to 12 VDC) 0 to 20 mA
(jumper configurable); software configurable.
Built-in snubbing diode to protect against back EMF, for example when used with a 12
VDC relay.
PWM control: adjustable period from 2 to 65 sec
Floating control:
minimum plus on/off: 500 ms
adjustable drive time period
60 mA maximum at 12 VDC (60
°C; 140°F)
Load Resistance: minimum resistance 200 ohms for 0 to 10 VDC and
0 to 12 VDC outputs, maximum 500 ohm for 0 to 20 mA output
Auto reset fuse
60 mA at 60
°C (140°F)
100 mA at 20
°C (68°F)
Output Resolution: 10-bit digital/does analog converter
Wireless Receiver
1
Communication: EnOcean® Wireless standard
Number of Wireless Inputs
2
: 28
Supported Wireless Receivers: LN-WMOD315-0 and LN-WMOD868-0
Telephone Cord Cable: Connector: 4P4C modular jack, Length: 6.5 ft (2 m)
Electromagnetic Compatibility CE Emission: EN61000-6-3: 2007 Generic standards for residential, commercial, and
light-industrial environments (pending).
CE Immunity: EN61000-6-1: 2007; Generic standards for residential, commercial, and
light-industrial environments (pending).
LN Series Communicating
Sensor
Communication: RS-485
Number of sensors per controller: up to 12, in daisy-chain configuration
Cable: Cat 5e, 8 conductor twisted pair
Connector: RJ-45
Compliance:
United States UL Listed, File E107041, CCN PAZX7,
Under UL 916, Energy Management Equipment
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
Canada UL Listed, File E107041, CCN PAZX7,
Under CAN/CSA C22.2 No. 205, Signal Equipment
Industry Canada, ICES-003
Europe CE Mark – Johnson Controls, Inc., declares that the products are in compliance with the
essential requirements and other relevant provisions of the EMC Directive 2004/108/EC.
1. Available when an optional external Wireless Receiver is connected to the controller. Some wireless inputs may use more
than one wireless input from the controller.
2. Some wireless modules may use more than one wireless input from the controller.
LN-PRG300-12 (Part 2 of 2)
