P—P70, P72, and P170 Controls for Low Pressure Applications Product/Technical Bulletin 11
E
lectrical Ratings
Table 4: SPST Electrical Ratings (P70A, B, C, and D, and P170A, C, and D Models)
Standard Single-Phase Ratings
Hermetic Compressor
Single-Phase Ratings
120 VAC 208 VAC 240 VAC 208/240 VAC
Motor Horsepower
1.5 3 3 --
Motor Full-Load Amperes
20 18.7 17 20
Motor Locked-Rotor Amperes
120 112.2 102 120
Non-Inductive Amperes
22 22 22 --
Pilot Duty
125 VA at 120 to 600VAC; 57.5 VA at 120 to 300 VDC
Table 5: SPDT Electrical Ratings 1hp Switch (P70E Models)
Standard Single-Phase Ratings
120 VAC 208 VAC 240 VAC 277 VAC*
Motor Full Load Amperes
16.0 9.2 8.0 7.0
Motor Locked Rotor
Amperes
96.0 55.2 48.0 42.0
Non-Inductive Amperes
16.0 9.2 8.0 -
Pilot Duty
125 VA at 120 to 600 VAC 125 VA at 24 to 600 VAC
* Rating for P70EC models only
Table 6: SPDT Electrical Ratings1/4 hp Switch (P70F Models)
Standard Single-Phase Ratings
120 VAC 208 VAC 240 VAC
Motor Full Load Amperes
6.0 3.3 3.0
Motor Locked Rotor
Amperes
36.0 19.8 18.0
Non-Inductive Amperes
6.0 6.0 6.0
Pilot Duty
125 VA at 24 to 240 VAC
Table 7: 4-wire, 2-circuit Electrical Ratings (P70G, H, J, and K, and P170K Models)
Standard Single-Phase Ratings
Line-M2 (Main Contacts) Line-M1 (Auxiliary Contacts)
120
VAC
208
VAC
240
VAC
277
VAC
120
VAC
208
VAC
240
VAC
277
VAC
Motor Full Load
Amperes
16.0 9.2 8.0 -- 6.0 3.3 3.0 --
Motor Locked Rotor
Amperes
96.0 55.2 48.0 -- 36.0 19.8 18.0 --
Non-Inductive
Amperes
16.0 9.2 8.0 7.2 6.0 6.0 6.0 6.0
Pilot Duty (for both
sets of contacts)
125 VA at 24 to 600 VAC; 57.5 VA at 120 to 300 VDC
