System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin32
Hybrid Analog and High Input Signal Selection Control System Example
Figure 13 shows a System 450 hybrid analog output control system example using
a C450CPW-100 control module with the hybrid analog output controlling the
speed of an EC condenser fan motor (for the cooling equipment condenser) based
on condenser pressure.
This example uses two P499 pressure transducers and the High Input Signal
Selection feature to control the condenser fan speed based on the highest pressure
sensed by the two transducers. The cooling equipment is controlled by an A99
temperature sensor.
Figure 13 also shows a System 450 control system that is set up to use the High
Input Signal Selection feature to control the hybrid analog output signal and the
motor speed of an EC condenser fan motor on the cooling equipment condenser.
Figure 14 shows the System 450 UI Main screens, System Status screens, and
System Setup screens for the control system example in Figure 13.
Figure 13: System 450 Hybrid Analog Output Control System Example with
Condenser Fan (EC) Motor Speed Control, High Input Signal Selection
F
I
G
:
C
4
5
0
C
P
W
1
0
0
a
p
p
a
n
l
g
e
x
m
p
l
L1
L2
L1
L2
Active/Passive Sensor DIP Switches
DIP Switch 1 and 2 are OFF; switch 3 is ON.
LC1
LNO1
LNC1
C450SBN-x
Expansion Module
OUTR2
C450CPW-100
Control Module
OUTA1
COM
AO1
WIRING
24V
Sn2
C
C
C
Sn1
Sn3
5V
WIRING
24V
Sn2
C
C
C
Sn1
Sn3
5V
240
VAC
120
VAC
Electronically Commutated
(EC) Motor Speed Control
Input Circuit
* Connect cable shields at only one
point to any “C” terminal on the
Input Terminal Block.
