System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin16
System 450 Sensors and Transducers for Standard Control Modules
Table 2 shows the Sensor Types, output setup values, value ranges, and product
types for the temperature sensors, humidity sensors, and pressure transducers that
are compatible with the C450CxN-x standard control module models.
Table 2: System 450 Sensor Types, Setup Values, and Sensor/Transducer
Product Codes
Sensor
Type
Unit of Measurement
Value
(Condition/Units)
Effective
Sensing
Range
Range of
Usable
Values
1
1. Because of the way that the System 450 Differential Sensor (Sn-d) is set up and calculated with two identical sensors
(Sn-1 and Sn-2), the Range of Usable Values is twice as large as a single sensor. See Table 5 on page 26 for the
Range of Usable Values when an output references Sn-d.
Resolution
Increment
Value
Minimum
Proportional
or Control
Band
Sensor Product
Type Number
2
2. See Repair and Ordering Information on page 62 (Table 12 through Table 20) for additional ordering information for
System 450 compatible sensors and transducers.
F F (Temperature/degrees) -46 to 255 -40 to 250 1 1 A99B-xxx
C C (Temperature/degrees) -43 to 124 -40 to 121 0.5 0.5 A99B-xxx
rH % (Humidity/%RH) 1 to 100 10 to 95 1 2 HE-67Sx-xxxxx
HE-67Nx-xxxxx
HE-68Nx-0N00WS
P 0.5 INWC (Pressure/in. W.C.) 0 to 0.5 0.025 to 0.5 0.005 0.025 DPT2650-0R5D-AB
P 2.5 INWC (Pressure/in. W.C.) 0 to 2.5 0.1 to 2.5 0.02 0.1 DPT2650-2R5D-AB
P 5 INWC (Pressure/in. W.C.) 0 to 5.0 0.25 to 5.0 0.05 0.25 DPT2650-005D-AB
P 8 bAR (Pressure/bar) -1 to 8 -1 to 8 0.05 0.1 P499Rxx-401C
P 10 INWC (Pressure/in. W.C.) 0 to 10 0.5 to 10 0.05 0.2 DPT2650-10D-AB
P 15 bAR (Pressure/bar) -1 to 15 -1 to 15 0.1 0.2 P499Rxx-402C
P 30 bAR (Pressure/bar) 0 to 30 0 to 30 0.1 0.4 P499Rxx-404C
P 50 bAR (Pressure/bar) 0 to 50 0 to 50 0.2 0.4 P499Rxx-405C
P 100 PSI (Pressure/psi) 0 to 100 0 to 100 0.5 1 P499Rxx-101C
P 110
3
3. See Active and Passive Sensors on page 17 for information on setting up System 450 outputs that reference the P 110
Sensor Type.
Hg/PSI (Pressure/Hg-psi) -10 to 100
(20 inHg to
100 psi)
-10 to 100 0.5 1 P499Rxx-100C
P 200 PSI (Pressure/psi) 0 to 200 0 to 200 1 1 P499Rxx-102C
P 500 PSI (Pressure/psi) 0 to 500 90 to 500 1 5 P499Rxx-105C
P 750 PSI (Pressure/psi) 0 to 750 150 to 750 2 6 P499Rxx-107C
HIF F (Temperature/degrees) -50 to 340
-40 to 340
4
4. Many of the temperature sensors that can be set up as HI°F or HI°C Sensor Types are not designed for use across the
entire Range of Usable Values for HI°F and HI°C Sensor Types. Refer to the Technical Specifications for the sensor
you intend to use to determine the condition range that the sensor is specified to be mounted and operate in.
1 1 TE-631x, TE-6000-x
TE-68NT-0N00S
HIC C (Temperature/degrees) -45.5 to
170
-40 to 170
4
0.5 0.5 TE-631x, TE-6000-x
TE-68NT-0N00S
