System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin 63
Table 12: System 450 Compatible A99B Temperature Sensors and Accessories
Ordering Information
1
Product Code
Number
Product Description
A99BA-200C PTC Silicon Sensor with Shielded Cable; Cable Length 2 m (6-1/2 ft);
Sensor Temperature Range: -40 to 120°C (-40 to 250°F)
Cable Jacket Temperature Range: -40 to 100°C (-40 to 212°F)
A99BB-25C PTC Silicon Sensor with PVC Cable; Cable Length 0.25 m (9-3/4 in.);
Sensor Temperature Range: -40 to 120°C (-40 to 250°F)
Cable Jacket Temperature Range: -40 to 100°C (-40 to 212°F)
A99BB-200C PTC Silicon Sensor with PVC Cable; Cable Length 2 m (6-1/2 ft);
Sensor Temperature Range: -40 to 120°C (-40 to 250°F)
Cable Jacket Temperature Range: -40 to 100°C (-40 to 212°F)
A99BB-300C PTC Silicon Sensor with PVC Cable; Cable Length 3 m (9-3/4 ft);
Sensor Temperature Range: -40 to 120°C (-40 to 250°F)
Cable Jacket Temperature Range: -40 to 100°C (-40 to 212°F)
A99BB-500C PTC Silicon Sensor with PVC Cable; Cable Length 5 m (16-3/8 ft);
Sensor Temperature Range: -40 to 120°C (-40 to 250°F)
Cable Jacket Temperature Range: -40 to 100°C (-40 to 212°F)
A99BB-600C PTC Silicon Sensor with PVC Cable; Cable Length 6 m (19-1/2 ft);
Sensor Temperature Range: -40 to 120°C (-40 to 250°F)
Cable Jacket Temperature Range: -40 to 100°C (-40 to 212°F)
A99BC-25C PTC Silicon Sensor with High Temperature Silicon Cable; Cable Length 0.25 m (9-3/4 in.)
Sensor Temperature Range: -40 to 120°C (-40 to 250°F)
Cable Jacket Rated for Full Sensor Temperature Range.
A99BC-300C PTC Silicon Sensor with High Temperature Silicon Cable; Cable Length 3 m (9-3/4 ft)
Sensor Temperature Range: -40 to 120°C (-40 to 250°F)
Cable Jacket Rated for Full Sensor Temperature Range.
A99BC-1500C PTC Silicon Sensor with High Temperature Silicon Cable; Cable Length 15 m (49 ft)
Sensor Temperature Range: -40 to 120°C (-40 to 250°F)
Cable Jacket Rated for Full Sensor Temperature Range.
BOX10A-600R PVC Enclosure for A99 Sensor; Includes Wire Nuts and Conduit Connector (for Outdoor Sensor)
WEL11A-601R Immersion Well for A99 Sensor Liquid Sensing Applications
A99-CLP-1 Mounting Clip for A99 Temperature Sensor
ADP11A-600R Conduit Adaptor, 1/2 in. Snap-Fit EMT Conduit Adaptor (box of 10)
TE-6001-1 Duct Mounting Hardware with Handy Box for A99 Sensor
TE-6001-11 Duct Mounting Hardware without Handy Box for A99 Sensor
SHL10A-603R Sun Shield (for Use with Outside A99 Sensors in Sunny Locations)
1. Refer to the A99B Series Temperature Sensors Product/Technical Bulletin (LIT-125186) on the Johnson Controls®
Product Literature website for more information.
Table 13: System 450 Compatible TE-6000 Series 1,000 Ohm Nickel Temperature
Sensors and Accessories Ordering Information
Product Code
Number
Product Description
TE-6000-x TE6000 Series 1,000 ohm at 70F nickel temperature sensors (only). Only the TE-6000-6 sensor
can be used for the entire HIC and HIF temperature range. Different sensing element packages
are available for various applications. For a complete list of compatible 1,000 ohm nickel sensors,
including sensor descriptions, technical specifications, and mounting accessories, refer to the
TE-6000 Series Temperature Sensing Elements Product Bulletin (LIT-216288). (System 450
Sensor Types HIC and HIF)
