System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin64
Table 14: System 450 Compatible TE-6300 Series 1,000 Ohm Nickel Temperature
Sensors and Accessories Ordering Information
Product Code
Number
Product Description
TE-631x-x TE6300 Series 1,000 ohm nickel averaging and 1,000 ohm thin-film nickel temperature sensors
(only). For a complete list of compatible 1,000 ohm nickel averaging and thin-film nickel sensors,
including sensor descriptions, technical specifications, and accessories, refer to the TE-6300
Series Temperature Sensors Product Bulletin (LIT-216320). (System 450 Sensor Types HIC and
HIF)
Table 15: System 450 Compatible TE-68NT-0N00S 1,000 Ohm Nickel Temperature
Sensor Ordering Information
Product Code
Number
Product Description
TE-68NT-0N00S TE6300 Series 1,000 ohm at 70F nickel averaging and 1,000 ohm thin-film nickel temperature
sensors (only). For a complete list of compatible 1,000 ohm nickel averaging and thin-film nickel
sensors, including sensor descriptions, technical specifications, and mounting accessories, refer
to the TE-6300 Series Temperature Sensors Product Bulletin (LIT-216320). (System 450 Sensor
Types HIC and HIF)
Table 16: System 450 Compatible HE67S3 Type Humidity Sensors with Integral A99B
Temperature Sensor Ordering Information
1
Product Code
Number
Product Description
HE-67S3-0N0BT Wall Mount Humidity Sensor with A99B Type Temperature Sensor: 10 to 90% RH;
-40 to 121C (-40 to 250F)
HE-67S3-0N00P Duct Mount Humidity Sensor with A99B Type Temperature Sensor: 10 to 90% RH;
-40 to 121C (-40 to 250F)
1. The HE-67S3 sensors require 24 VAC input and must use the 0–5 VDC output. Refer to the TrueRH Series HE-67xx
Humidity Element with Temperature Sensors Product Bulletin (LIT-216245) on the Johnson Controls Product Literature
website for more information, including technical specifications and mounting accessories.
Table 17: System 450 Compatible HE6800 Series Humidity Transmitters with
Temperature Sensor Ordering Information
1
Product Code
Number
Product Description
HE-68N2-0N00WS Wall Mount Humidity Transmitter with Nickel Temperature Sensor: 10 to 90 ±2% RH;
0 to 55C (32 to 131F)
HE-68N3-0N00WS Wall Mount Humidity Transmitter with Nickel Temperature Sensor: 10 to 90 ±2% RH;
0 to 55C (32 to 131F)
1. The HE-6800 transmitters require 24 VAC input and must use the 0–5 VDC output. Refer to the HE-6800 Series Humidity
Transmitters with Temperature Sensor Product Bulletin (LIT-12011625) on the Johnson Controls Product Literature website
for more information, including technical specifications and mounting accessories.
Table 18: System 450 Compatible Low Pressure Differential Transducer Ordering
Information
1,2
Product Code
Number
Product Description
DPT2650-0R5D-AB Low Pressure Differential Transducer: 0 to 0.5 in. W.C. (System 450 Sensor Type: P 0.5)
DPT2650-2R5D-AB Low Pressure Differential Transducer: 0 to 2.5 in. W.C. (System 450 Sensor Type: P 2.5)
DPT2650-005D-AB Low Pressure Differential Transducer: 0 to 5.0 in. W.C. (System 450 Sensor Type: P 5)
DPT2650-10D-AB Low Pressure Differential Transducer: 0 to 10 in. W.C. (System 450 Sensor Type: P 10)
