System 450™ Series Modular Control Systems with Standard Control Modules Technical Bulletin66
P499RAP-102C 0 to 200 psig; Order a WHA-PKD3 type wire harness separately.
P499RAP-105C 0 to 500 psig; Order WHA-PKD3 type wire harness separately.
P499RAP-105K 0 to 500 psig; WHA-PKD3-200C wire harness included.
P499RAP-107C 0 to 750 psig; Order WHA-PKD3 type wire harness separately.
P499RAP-107K 0 to 750 psig; WHA-PKD3-200C wire harness included.
1. The P499 sensors must be powered with the +5 VDC and C terminals and the output is 0.5 to 4.5 VDC. Refer to the
P499 Series Electronic Pressure Transducers Product/Technical Bulletin (LIT-12011190) on the Johnson Controls
Product Literature website for more information.
Table 21: WHA-PKD3 Wire Harnesses Ordering Information
1
Product Code
Number
Product Description
WHA-PKD3-200C Plug and 3-Wire Harness for P499 Electronic Pressure Transducers: 2.0 m (6-1/2 ft) cable
WHA-PKD3-400C Plug and 3-Wire Harness for P499 Electronic Pressure Transducers: 4.0 m (13 ft) cable
WHA-PKD3-600C Plug and 3-Wire Harness for P499 Electronic Pressure Transducers: 6.0 m (19-5/8 ft) cable
1. Refer to the P499 Series Electronic Pressure Transducers Product/Technical Bulletin (LIT-12011190) on the
Johnson Controls Product Literature website for more information.
Table 20: System 450 Compatible P499 Series Transducers with 1/8 in. 27 NPT External
Thread (Style 49) Ordering Information
1
(Part 2 of 2)
Product Code
Number
Product Description

Johnson Controls Penn System 450 Series Specifications

General

Brand	Johnson Controls
Model	Penn System 450 Series
Category	Control Systems
Language	English
