T600HPx-4 and T600HPx-4+PIR Series Heat Pump Thermostat Controllers Installation Instructions 13
Operation
Setup/Operation of the T600HPx-4 or
T600HPx-4+PIR Series Thermostat Controller
Once the thermostat controller is configured via the
Installer Configuration Menu, set up its operating
parameters via the Main User Menu. Access this menu
by pressing the MENU key during normal thermostat
controller operation. The Main User Menu contains the
basic operating features of the thermostat controller.
The Main User Menu also uses Auto Help, which is
displayed automatically in the menu when there is a
pause in setup activity. To exit Auto Help, continue with
the setup selection. When the thermostat controller is
in the Main User Menu and is left unattended for
45 seconds, the menu reverts to the Status Display
Menu.
Follow the steps in Table 3 to set up the thermostat
controller.
Comp/aux Sets the mode of interaction
between the heat pump and the
auxiliary heat.
Default: off
(on): In the heating mode only. If the heat pump is not able to satisfy
the heating setpoint, the auxiliary heat is energized and the heat
pump is shut off. This typically applies when the air handler heat
pump coil is installed after the auxiliary heat. There is a 2-minute
delay to restart the heat pump after the auxiliary heat is shut down.
(off): In the heating mode only. If the heat pump is not able to satisfy
the heating setpoint, the auxiliary heat is energized at the same time
as the heat pump stage. This typically applies when the air handler
heat pump coil is installed before the auxiliary heat (all electric
systems).
1. Setting DI1 or DI2 to RemNSB disables schedules and stops the Schedule menu display. Any other setting enables
schedules and the Schedule menu (T600HPP-4 and T600HPP-4+PIR models).
2. T600HPP-4 and T600HPP-4+PIR models.
3. When adjusting the numeric value, press the UP/DOWN arrow key to change the value by single increments; press and
hold the UP/DOWN arrow key to change the numeric value in increments of ten.
4. When adjusting the temperature, press the UP/DOWN arrow key to change the value in 0.5F°/0.5C° increments; press and
hold the UP/DOWN arrow key to change the value in 5.0F°/5.0C° increments.
5. When the outside air temperature sensor is not connected or it has a short, the thermostat controller bypasses heating
lockout, cooling lockout, high balance point, and low balance point. An emergency mode bypasses heating lockout and
permits auxiliary heating whenever a heating demand occurs.
Table 2: Installer Configuration Menu (Part 7 of 7)
Parameter
Appearing
on Display
Description and Default Selection Options
Table 3: Setting Up the T600HPx-4 or
T600HPx-4+PIR Series Thermostat
Controller (Part 1 of 2)
Thermostat
Controller
Display
Description
Press the MENU key while in the
Status Display Menu to enter the
Main User Menu.
Overrides Unoccupied Setpoints
Only Appears if Thermostat
Controller is in Unoccupied State
See Enabling Temporary Override
Schedule on page 14.
Cancels Override Mode
Sets the Temperature Setpoints
See Entering Permanent
Temperature Setpoints on page 14.
Selects the System Mode
Default: Automatic (auto)
See Selecting the System Mode
on
page 16.
RoomTemp
75.0
°
F
Override
schd Y/N
Cancel
ovrd Y/N
Temperat
set? Y/N
Sys mode
set? Y/N
