TEC3000 Series Single- or Two-Stage Economizer Thermostat Controllers Installation Instructions
35
System Status Occupancy Source Occupancy Sensor Occupancy BI
Temp Occ BI
Temp Occ
Occ Override
Local Schedule
BAS Schedule
Occupancy Sensor
Unit Status Idle System Fault
Airflow Fault
Open Window
Control Off
Unreliable Temperature
Dehumidification
Idle
Cooling
Heating
Cooling Unavailable
Heating Unavailable
Cooling Unavailable due to Changeover
Cooling Unavailable due to OA Temp
Cooling Unavailable due to Control Mode
Heating Unavailable due to Changeover
Heating Unavailable due to OA Temp
Heating Unavailable due to Control Mode
Supply Air Temperature 75°F -50 to 250°F (-45 to 121°C)
Cooling OAT Lockout Inactive Active or Inactive
Heating OAT Lockout Inactive Active or Inactive
Comp Low OAT Lockout Inactive Active or Inactive
Supp High Lockout Temp Inactive Active or Inactive
Zone Temp Source Internal Sensor Unreliable
Internal Sensor
Remote Sensor
Network Override
Input Not Installed
Control Status Cooling % Command 0% 0 to 100%
Heating % Command 0% 0 to 100%
Supplemental % Command 0% 0 to 100%
Supplemental Heat Command Off On or Off
Fan On On or Off
Controller Info Model Name TEC3x3x-xx
—
Software Version x.x.x.xxxx —
Unit Name TECxxxxx —
Device Name — User-Supplied
Device Description TEC3000
—
Table 10: Menus and Submenus (Part 8 of 9)
Level 1 Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
1
