Table 17: Troubleshooting details
Symptom Probable causes Solutions
The touchscreen is unresponsive.
You do not tap the touchscreen,
but the display acts as if it is
tapped, which causes the display
to blink or toggle between
screens.
You need to tap the display at
an offset from a touch point to
activate the display.
You tap the display or touch the
controller within 5 mm of the
display when power is applied to
the controller.
Reboot the controller. Do not interact with the
controller until the home screen displays.
Note: For common MS/TP troubleshooting information, refer to the MS/TP Communications Bus Technical Bulletin
(LIT-12011034).
TEC3000 Series Proportional Fan Coil Thermostats technical specifications
Table 18: TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat
Controllers with Dehumidification Capability technical specifications
Specification Description
Power requirements 19 VAC to 30 VAC, 50/60 Hz, 4 VA at 24 VAC nominal, Class 2 or safety extra-low
voltage (SELV)
USB port power rating 120 mA to 250 mA current draw supported
Analog output rating 0 VDC to 10 VDC into 2k ohm resistance (minimum)
Fan relay output rating 19 VAC to 30 VAC, 1.0 A maximum, 15 mA minimum, 3.0 A in-rush
Auxiliary output rating/triac output 19 VAC to 30 VAC, 1.0 A maximum, 15 mA minimum, 3.0 A in-rush
Binary inputs Dry contact across terminal COM to terminals BI1, BI2, or COS
Analog inputs Nickel, platinum, A99B, 2.25k ohm NTC, 10k ohm NTC, 10k ohm NTC Type 3
across terminal COM to terminals R SEN or COS
Temperature sensor type Local digital sensor
Wire size 18 AWG (1.0 mm diameter) maximum, 22 AWG (0.6 mm diameter)
recommended
For wired models: Up to 100 devices maximum for each Metasys Supervisory
Engine; 4,000 ft (1,219 m) maximum cable length. Refer to the MS/TP Technical
Bulletin for the Metasys, FX, or Verasys
®
system installed.
MS/TP network guidelines
For wireless models: Up to 100 devices maximum for each Metasys Supervisory
Engine
Wireless band (for wireless models) Direct-sequence spread-spectrum 2.4 GHz ISM bands
TEC30xx-1x-000
compatible with
ZFR182x Pro
Series
10 mW maximumTransmission
power (for
wireless models)
TEC31xx-1x-000
compatible with
ZFR183x Pro
Series
100 mW maximum
TEC30xx-1x-000
compatible with
ZFR182x Pro
Series
50 ft (15.2 m) recommended indoor
250 ft (76.2 m) line of sight, maximum
Transmission
range (for wireless
models)
TEC31xx-1x-000
compatible with
ZFR183x Pro
Series
250 ft (76.2 m) recommended indoor
1000 ft (304.8 m) line of sight, maximum
TEC3000 Series Proportional Fan Coil Thermostats Installation Guide38
