SECTION XIII: START UP SHEET
33" 95% AFUE Single Stage Gas Furnace Start Up Sheet
Proper furnace start up is critical to customer comfort and equipment longevity
Name Address
City State or Province Zip or Postal Code
Furnace Model Furnace Serial
Evaporator Coil Model Evaporator Coil Serial
Upflow Downflow Horizontal Left Horizontal Right
Unit is level
Venting system is the proper size, within the limitations of the chart in the installation instructions,
properly connected to the furnace, and properly pitched
Condensate drain is connected
Filter Type
Intake Size
Exhaust Size
# of 90 Degree Ells # 0f 45 Degree Ells Length
Length # 0f 45 Degree Ells# of 90 Degree Ells
Polarity is correct (black is L1 (hot), white is N (neutral) Ground wire is connected
Line voltage value to furnace (volts AC)
Low voltage value between "R" and "C" on furnace control board (volts AC)
Thermostat Type
Other System Equipment and Accessories
Owner Information
Equipment Data
Furnace Configuration
Condensate Management
Venting
Electrical: Line Voltage
Outdoor Unit Model Outdoor Unit Serial
Filter, Thermostat, Accessories
Filter Location(s)
Connections -- All Per Installation Instructions and Local Code
Gas piping is connected (including drip leg) Supply plenum and return air are connected
Filter Size
Vent system is connected
Thermostat wiring is complete Thermostat heat anticipator set to .40 (if present)
Electrical: Low Voltage
Technician Performing Start-Up Installing Contractor Name
Start-Up Date
Condensate tubing is correctly installed for the furnace position
