Johnson Controls tyco iSTAR Edge G2 User Manual

8
Wiring
Wiring Specifications and Components
Signal From To AWG Shield Max Length
RS-485 Comm,
two wire
iSTAR Edge
G2
RM and I/O
Modules
22 Yes 4000 ft (1212m)
Power iSTAR Edge
G2
RM and I/O
Modules
22/18 No Range of 600 ft to
1500 ft, depending on
AWG used.
RJ-45-Ethernet iSTAR Edge
G2
Hub, Host Cat 5e
24
N/A 328 ft (100m)
Supervised Input iSTAR Edge
G2
Input 22/18 No 2000 ft (606m)
Request-to-exit
(REX or RTE)
iSTAR Edge
G2
Switch 22/18 No 2000 ft (606m)
Door Contact (DSM) iSTAR Edge
G2
Contact 22/18 No 2000 ft (606m)
Supervised Input iSTAR Edge
G2
Input 22 Yes 2000 ft (606m)
Reader Input iSTAR Edge
G2
Proximity/Wiegand
signaling read
head
22
20
18
Yes 200 ft (60.96m)
300 ft (91.4m)
500 ft (152.4m)
Table 4:iSTAR and Components Wiring Specifications
■ There are 2 jumpers on the PoE module:
• x1 jumper to select PoE or PoE Plus (+). Ensure the jumpers are set correctly if using PoE.
• x1 jumper to configure the voltage used to power the Edge G2 and to supply the wet relays for door locks. Set the
jumper to 24 VDC for the Edge G2.
■ Do not connect the PoE injector to a receptacle controlled by a switch.
■ The Tamper, Battery Low, and AC Power Fail inputs must be enabled and connected to report to comply with UL
requirements.
NOTE
Shielded cable must be used for AC Fail in Low Battery input connections.
Supervised Inputs must use shielded, 22 AWG (minimum) stranded, twisted-pair cable, such as Belden 9462 or equivalent, for
monitor points, DSMs, and REXs.
Wiring methods must be in accordance with the National Electrical Code, ANSI/NFPA 70.
Connections between PSE or power injector and the PD must use 26 AWG (0.13mm2) for patch cords and 24 AWG (0.21mm2) for
horizontal or riser cables connected through standard 8-pin RJ-45 connectors.
