PB_VA-748x_12 2012
Building■Efciency
Headquarters: Milwaukee, Wisconsin, USA
Branch Officies: Principal Cities World-wide
Metasys
®
and Johnson Controls
®
are registered trademarks of Johnson Controls, Inc.
All other marks herein are the marks of their respective owners.
© Copyright 2012 Johnson Controls, Inc. All rights reserved. Any unauthorized use or copying is strictly prohibited.
www.johnsoncontrols.com
Technical■Specictions
Actuator■Models VA-7480-00x1 VA-7481-00x1 VA-7480-00x3 VA-7481-00x3 VA-7482-x0x1
Action■Control
Floating or PAT Proportional
Supply■Voltage■(50/60Hz)
24VAC +/-15% 230VAC +/-10%
24VAC +/-15%
24VDC +/-15%
Input■Impedance
- Voltage
--- >100 kΩ
- Current
--- 500 Ω
Power■Consumption
- Apparent
2.5 VA 6.0 VA 2.5 VA
- Active
1.5 W 2.2 W 1.5 W
Maximum■■Mechanical■Stroke
6.3mm
Running■Time
13 sec/mm 8 sec/mm 13 sec/mm 8 sec/mm 8 sec/mm
Protection
IP43
Material
- Cover
ABS + PC
- Yoke
PA66 – Glass Mineral filled (30% total)
- Thread Nut
Brass CuZn40Pb2
Housing■colour
White semitransparent
Thread■Nut■Connection
See ordering code
Ambient■Operating■■Condition
0 °C to 50 °C, non condensing
Ambient■Storage■Condition
-20 °C to 65 °C, non condensing
Max.■Fluid■Temperature
95 °C
Electrical■Connections 1.5m cable length
(3 x 0.35mm
2
)
1.5m cable length
(3 x 0.75mm
2
)
1.5m cable length
(3 x 0.35mm
2
)
Operating■Status■Indications
LED
Audible■Noise■Rating
< 30 dB(A)
Shipping■Weight
0.2 Kg
■■■Compliance
Johnson Controls, Inc., declares that this product is in compliance with the essential
requirements and other relevant provisions of the EMC Directive 2004/108/EC and
Low Voltage Directive 2006/95/EC.
