FORM 145.13-NO2
ISSUE DATE: 1/22/2020
SECTION 2 - OPERATION
NAME VALUE UNIT
99 START-UP DATA
01 LANGUAGE ENGLISH
02 APPLIC MACRO HVAC DEFAULT
05 MOTOR NOM VOLT DRIVE DEPENDENT V
06 MOTOR NOM CURR DRIVE DEPENDENT A
07 MOTOR NOM FREQ 60 Hz
08 MOTOR NOM SPEED DRIVE DEPENDENT rpm
09 MOTOR NOM POWER DRIVE DEPENDENT hp
10 START/STOP.DIR
01 EXT1 COMMAMDS DI1
02 EXT2 COMMANDS DI1
11 REFERENCE SELECT
01 KEYPAD REF SEL REF1 (Hz/rpm)
02 EXT1/EXT2 SEL EXT2
03 REF1 SELECT KEYPAD
04 REF1 MIN 0 Hz
05 REF1 MAX 60 Hz
06 REF2 SELECT AI1
07 REF2 MIN 0
08 REF2 MAX 100
13 ANALOGUE INPUTS
01 MINIMUM AI1 20 %
02 MAXIMUM AI1 100 %
14 RELAY OUTPUTS
01 RELAY OUTPUT 1 FLT/ALARM
16 SYSTEM CONTROLS
01 RUN ENABLE DI1
20 LIMITS
03 MAX CURRENT DRIVE DEPENDENT A
07 MINIMUM FREQ 30 Hz
08 MAXIMUM FREQ 60 Hz
34 PANEL DISPLAY
01 SIGNAL1 PARAM OUTPUT FREQ
02 SIGNAL1 MIN 0 Hz
03 SIGNAL1 MAX 60 Hz
04 OUTPUT1 DSP FORM +0.0
05 OUTPUT1 UNIT Hz
06 OUTPUT1 MIN 0
07 OUTPUT1 MAX 60
08 SIGNAL2 PARAM CURRENT
09 SIGNAL2 MIN A 0
10 SIGNAL2 MAX A 0
11 OUTPUT2 DSP FORM DIRECT
TABLE 1 - DSH/DSV ONLY FACTORY PARAMETERS FOR MULTI SPEED EVAPORATOR APPLICATION -
208/230 AND 460 VAC (ABB ACS320)
