Johnson Controls VFD Series User Manual

13
SECTION 2 - OPERATION
FORM 145.13-NO2
ISSUE DATE: 1/22/2020
2
NAME VALUE UNIT
12 OUTPUT2 UNIT A
13 OUTPUT2 MIN 0
14 OUTPUT2 MAX 0
TABLE 1 - DSH/DSV ONLY FACTORY PARAMETERS FOR MULTI SPEED EVAPORATOR APPLICATION -
208/230 AND 460 VAC (ABB ACS320) (CONT'D)
TABLE 2 - DSH/DSV ONLY FACTORY PARAMETERS FOR LOW AMBIENT CONDENSER APPLICATION
208/230 AND 460 VAC (ABB ACS320)
NAME VALUE UNIT
99 START-UP DATA
01 LANGUAGE ENGLISH
02 APPLIC MACRO CONDENSER
05 MOTOR NOM VOLT DRIVE DEPENDENT V
06 MOTOR NOM CURR DRIVE DEPENDENT A
07 MOTOR NOM FREQ 60 Hz
08 MOTOR NOM SPEED DRIVE DEPENDENT rpm
09 MOTOR NOM POWER DRIVE DEPENDENT hp
10 START/STOP/DIR
01 EXT1 COMMANDS NOT SEL
02 EXT2 COMMANDS DI1
03 DIRECTION FORWARD
11 REFERENCE SELECT
01 KEYPAD REF SEL REF1 (Hz/rpm)
02 EXT1/EXT2 SEL EXT2
03 REF1 SELECT KEYPAD
04 REF1 MIN 0 Hz
05 REF1 MAX 60 Hz
06 REF2 SELECT PID1OUT
07 REF2 MIN 0 %
08 REF2 MAX 100 %
13 ANALOGUE INPUTS
01 MINIMUM AI1 0 %
02 MAXIMUM AI1 100 %
14 RELAY OUTPUTS
01 RELAY OUTPUTS 1 FLT/ALARM
16 SYSTEM CONTROLS
01 RUN ENABLE DI1
08 START ENABLE 1 DI1
20 LIMITS
03 MAX CURRENT DRIVE DEPENDENT A
07 MINIMUM FREQ 15 Hz
08 MAXIMUM FREQ 60 Hz
34 PANEL DISPLAY
01 SIGNAL1 PARAM OUTPUT FREQ
02 SIGNAL1 MIN 0
