SECTION 2 - OPERATION
NAME VALUE UNIT
03 SIGNAL1 MAX 60
05 OUTPUT1 UNIT Hz
08 SIGNAL2 PARAM PID 1 SETPNT
11 OUTPUT2 DSP FORM DIRECT
40 PROCESS PID SET 1
04 PID DERIV FILTER 1
05 ERROR VALUE INV YES s
06 UNITS PSI
08 0% 0 PSI
09 100% VALUE 750 PSI
10 SET POINT SEL INTERNAL
11 INTERNAL SETPNT 320 PSI
16 ACT1 INPUT AI1
TABLE 2 - DSV ONLY FACTORY PARAMETERS FOR LOW AMBIENT CONDENSER APPLICATION - 208/230
AND 460 VAC (ABB ACS320) (CONT'D)
TABLE 3 - DSH/DSV ONLY FACTORY PARAMETERS AND SIGNALS FOR 575V EVAPORATOR SETTINGS
(ABB ACS250)
NAME VALUE UNIT
99 START-UP DATA
02 APPLIC MACRO 1
05 MOTOR NOM VOLT DRIVE DEPENDENT V
06 MOTOR NOM CURR DRIVE DEPENDENT A
07 MOTOR NOM FREQ DRIVE DEPENDENT Hz
08 MOTOR NOM SPEED DRIVE DEPENDENT rpm
11 REFERENCE SELECT
03 PRIMARY COMMAND 0:TERMINAL CONTROL
13 ANALOG INPUTS
00 ANALOG INPUT 1 U 0 - 10
14 RELAY OUTPUTS
01 USER RELAY OUTPUT 12: DRIVE TRIPPED
20 LIMITS
17 MAXIMUM MOTORING 100 %
CURRENT LIMIT
26 MOTOR CONTROL
03 V/F MODE VOLTAGE
BOOST
AUTO
SEC PARAMETERS
1ClgStg% - 38% (CV INTELLISPEED 1 STG COOL)
2ClgStg% - 50% (CV INTELLISPEED 2 STG COOL)
3ClgStg% - 69% (CV INTELLISPEED 3 STG COOL)
4ClgStg% - 100% (CV INTELLISPEED 4 STG COOL)
