Johnson Controls Y20EBD Series User Manual

24 M Motor Actuators
—
Y20EBD Valve Linkage for M100 Motor Actuators
Replacement Parts
Table 3 shows replacement parts that may be ordered from your nearest
Johnson Controls branch or distributor.
Table 3: Y20 Linkage Repair Parts
Description Code Number Remarks
Gear Assembly
GER18A-600 Includes CVR115-1 and GER28-1
Gear Only
GER28-1
Gear Cover
CVR115-1 Includes Mounting Screws
Spring Housing
and Rack
Assembly *
RCK12A--620
RCK12A--621
RCK12A--622
RCK12A--623
RCK12A--624
RCK12A--626
270 lb (1201 N) -- used with Y20EBD-3
179 lb (796 N) -- used with Y20EBD-4
150 lb (667 N) -- used with Y20EBD-2
75 lb (334 N) -- used with Y20EBD-1
40 lb (178 N) -- used with Y20EBD-5
100 lb (445 N) -- used with Y20EBD-6
* Rack and Spring Housing are an assembly with spring and standard connector (1/4-28)
installed.
Specify Spring Load for application when ordering.
Table 4: Accessories
Description Part Number
5/16 inch Stem Connector
Y20EBE-1
VT Adapter Kit
Y20EBE-2
