Manual description Form number
Wiring Diagram – Field Connections for YK Chiller (Style G) OptiView
™
Control
Center with Remote Medium Voltage VSD
160.75-PW3
Wiring Diagram – Field Control Modifications for YK Chiller (Style G) 160.75-PW4
Wiring Diagram – YK Chiller (Style G) OptiView
™
Control Center with Remote Low
or Medium Voltage EMS
160.75-PW5
Wiring Diagram – YK Chiller (Style G) OptiView
™
Control Center with Unit Mounted
Low or Medium Voltage SSS, Unit Mounted Low Voltage VSD with Modbus, or
Remote Medium Voltage VSD
160.75-PW6
Wiring Diagram – YK Chiller (Style G) OptiView
™
Control Center with LTC I/O Board
with Remote Low or Medium Voltage EMS
160.75-PW7
Wiring Diagram – YK Chiller (Style G) OptiView
™
Control Center with LTC I/O Board
with Unit Mounted Low or Medium Voltage SSS, Unit Mounted Low Voltage VSD
with Modbus or Remote Medium Voltage VSD
160.75-PW8
Renewal Parts – Unit 160.75-RP1
Renewal Parts – OptiView
™
Control Center
160.54-RP1
Conditioned based maintenance
Traditional chiller maintenance is based upon assumed and generalized conditions. In lieu of
the traditional maintenance program, a Johnson Controls YORK conditioned based maintenance
(CBM) program can be substituted. This CBM service plan is built around the specific needs for
the chiller, operating conditions, and annualized impact realized by the chiller. Your local Johnson
Controls Branch can propose a customized Planned Service Agreement that leverages real time
and historical data, delivering performance reporting, corrective actions required and data enabled
guidance for optimal operation and lifecycle assurance. The program will include fault detection
diagnostics, operation code statistics, performance based algorithms and advance rules based
rationale delivered by the Johnson Controls Connected Equipment Portal.
Nomenclature
7Model YK Style G R-134a or R-513A
To Next Page
