Installation procedure
Unit pipe spec and connection method (unit: mm)
A. Outdoor unit
B. Indoor unit
C. Pipe spec and the torque
Model
Gas pipe Liquid pipe
Diameter
(mm)
Connecting method
Diameter
(mm)
Connecting method
YV2VYH010KAR-D-X
15.88
Flared
9.52
Flared
YV2VYH015KAR-D-X
19.05 9.52
YV2VYH015KAS-D-X
19.05 9.52
YV2VYH018KAS-D-X
19.05 9.52
Model
Capacity
Gas pipe Liquid pipe
Diameter
(mm)
Connecting method
Diameter
(mm)
Connecting method
09
9.52
Flared
6.35
Flared
12
12.7 6.35
16
12.7 6.35
18
12.7 6.35
24
15.88 9.52
Diameter (mm) Thickness (mm) Torque(N·m)
6.35 0.8 16~20
9.52 0.8
40~50
12.7 1.0
15.88 1.0 90~120
19.05 1.0 100~140
