Monitor tool

2. Outdoor unit PCB dipswitch setting, attention the different PCB version.

0151800123 PCB for YV2VYH015/018

0151800123A PCB for YV2VYH010/015/018

SW01 identify

SW01

SW02

OFF AC fan motor Ruking protocol (YV2VYH015KAR-D-X)

Renesas protocol (YV2VYH015/018KAS-D-X)DC fan motorON

1 2 3 4

0 0 0 -

0 0 1 -

0 1 0 -

0 1 1 -

1 0 0 -

1 2

Function

Reserved

YV2VYH015KAR-D-X

YV2VYH015KAS-D-X

YV2VYH018KAS-D-X

Select outdoor unit model under this position

Lock outdoor unit model (change to OFF position to re-select

outdoor unit model)

SW02 identify

SW01 SW02 Function identify LED2 Flashing times

1 2 3 4 1 2

— 0 0 — 0 1 YV2VYH010KAR-D-X 2

— 0 1 — 0 0 YV2VYH015KAR-D-X 4

— 1 0 — 0 0 YV2VYH015KAS-D-X 5

— 1 1 — 0 0 YV2VYH018KAS-D-X 6

0 — — — — — AC fan motor —

1 — — — — — DC fan motor —

— — — 0 — —

Select outdoor unit

model under this

position

—

— — — 1 — —

Lock outdoor unit

model (change to OFF

position to re-select

outdoor unit model)

LED2 change to

indication lamp for

indoor and outdoor unit

communication after

conrming model
