12
Installation procedure
Manifold pipe
Outdoor unit type
Manifold pipe selection:
Note:
1. When connecting the pipe and the outdoor, please pay attention to the outdoor pipe
dimension.
2. When adjusting the diameter among pipes and among the units, please must execute at the
branch pipe side.
3. When welding with hard solder, please must blow nitrogen. If not, a number of oxide will be
produced and cause heavy damage.Besides,to prevent water and dust into the pipe, please
make the brim as outer roll.
Total indoor capacity(100W) Model(optional)
Less than 335 FQG-B335A
