2 ©2010 Johnson Level & Tool - Rev. 1
Table of Contents
1. Kit Contents
2. Features and Functions
3. Safety Instructions
4. Location/Content
of Warning Labels
5. Location of Parts/Components
6. Operating Instructions
7. Using the Product
8. Self-Check & Fine Calibration
9. Technical Specifications
10. Application Demonstrations
11. Care and Handling
12. Product Warranty
13. Warranty Registration
14. Accessories
1. Kit Contents
Description Qty.
Self-Leveling Five-Beam Laser Dot 1
Multi-functional Magnetic Base 1
Mounting Strap 1
“AA” Alkaline Batteries 3
Tinted Goggles 1
Magnetic Target 1
Instruction Manual with Warranty Card 1
Soft-sided Carrying Case 1
2. Features and Functions
• Product simultaneously projects five laser beams (up, down,
front, left and right directions).
• Magnetic dampened compensation system.
• Maintains level even when effected by vibration on the job site.
• Laser beam flashes and sounds audible alarm when product is
beyond leveling range.
• Low voltage indication when power indication lamp is flashing.
• Pendulum locking mechanism helps protect units inner mechanisms.
• Multi-functional magnetic base for attaching to tripod or any
metal surface.
• Dust and rain resistant.
