©2010 Johnson Level & Tool - Rev. 1 7
7. Using the Product
This laser level was designed for various mounting applications.
1. Position laser base so laser beam shoots
between the feet of the base for plumb
applications.
2. Base top being rotated to shoot the laser
beam down the back of the base.
3. Position base by rotating top to shoot beam
down the back of the base. Ideal for use
with metal track.
4. Rare earth magnets located on base allows
the base to attach to metal surfaces.
3589H-New_Manuals 7/8/10 9:39 AM Page 7
