PEDAL AXLE-PULLEY ASSEMBLY REPLACEMENT
PROCEDURE
Tools required:
Philips screwdriver
C-clip pliers
Crank extractor
Coin
Hex key (4mm)
Open-end wrench
(14&17 mm)
Procedure:
5. Remove the c-clip (C) by using the c-clip pliers and
remove the metal pulley from the generator using
the Bearing Puller.
6. Remove the c-clip (D) by using the c-clip pliers and
remove the idler using the Bearing Puller.
7. Remove the c-clip (B) by using the c-clip pliers and
remove the Bearing Housing using the Bearing
Puller.
8. Replace the axle-pulley assembly with a new one.
9. Reverse step 1-9 to install the parts.
