PEDAL AXLE-PULLEY ASSEMBLY REPLACEMENT
PROCEDURE
ools required:
Philips screwdriver
C-clip pliers
Crank extractor
Coin
Hex key (4mm)
ch
(14&17 mm)
1.
iver, then remove footpad, guard and
2. e
3. e
ng
is
operation
so you will not damage both you and
e front
4.
ove the
Bearing Housing
T
Open-end wren
Pr cedure:
Remove the crank cover and screw, then remove the
crank. Loosen the screws from the side cover with
the screwdr
o
side cover.
Loosen the screw (A) and remove it (for th
axle-pulley assembly of the new design).
Remove the spring attaching the idler pulley to th
frame first, then loosen the screws attaching the
bearing housing to the axle-pulley assembly usi
the hex key (4mm) (The spring replacement
dangerous. Take special cautions during the
other parts, then
remove th
pulley)
Remove the c-clip
(B) by using the
c-clip pliers and
using the Bearing
Puller rem
To Next Page
