screws, tighten the remaining eight screws and
torque 60 to 84
in.
Ibs.
(7
to 9 N·m).
Tighten the three lower crankcase head screws
and torque
60
to 84
in
.
Ibs
.
(7
to 9 N·m).
Apply
Gasket Sealing Compound to outside metal
casing of a new upper main bearing seal. Using
Seal Installer,
PIN
321539, install the seal with its
lip facing down.
Lightly coat both sides of a new cylinder head
gasket with
Gasket Sealing Compound. Install the
gasket and
cylinder head. Tighten the screws
in
the sequence shown and torque 216 to 240
in.
Ibs.
(24 to 27 N·m).
POWERHEAD
ASSEMBLY - 25/30
Place the thermostat and the seal
in
the cavity
provided
in
the cylinder head. Set the spring
on
top of the thermostat.
3----,~
__
,
I
1-
___
~
2-
1.
Thermostat
2. Seal
3.
Spring
COA1452
Apply Gasket Sealing Compound to both sides of
a new cylinder head water cover gasket; install the
gasket and cover. Starting with the center screws
and working outward, tighten the screws and
torque
60 to 84
in.
Ibs.
(7
to 9 N·m). Install the cyl- 7
inder head screws
dry.
Do
not use sealant on
threads.
24941
Install the inner and outer exhaust covers. Coat
Torque Sequence
COA1476 both sides of two new gaskets with Gasket Seal-
ing Compound. Install the screws. Starting with
the center screws and working outward, tighten
E
o
o
~
><
~
OJ
~
c.
211
E
