542933-UIM-C-0112
Johnson Controls Un
itary Products
7
FIGURE 4:
High Level Wiring Path
FIGURE 5:
Communicating Plug Harness
FIGURE 6:
Wiring Diagra
m (Fully communicating system compo
nent
s)
ARC
B
COMM.
COMM.
A
- GREEN WIRE
R - RED WIRE
C - BLACK WIRE
B - BLUE (WHITE WIRE)
ARC
B
ARC
B
ARC
B
WHITE (B)
BLACK (C)
RED (R)
GREEN (A)
1
2
3
4
T
ouch Screen
Communicating Control
VS
Air Handler/Furnace
Communicating Control
Air Conditioner/Heat Pump
Communicating Control
A+
R
C
B-
A+
R
GND
B-
A+
R
C
B-
6
8
Table of Contents
Default Chapter
1
Table of Contents
1
General
2
Safety Considerations
2
Inspection
2
Limitations
2
Installation
3
Location
3
Mounting the Touch Screen Communicating Control
4
Removing Control Mounting Back Plate
5
Wiring Communication
6
Wiring Requirements
6
System Wiring Overview
6
Humidifier Connection
13
Initial Power-Up
15
Power-Up Sequence (System Master)
16
System Configuration
16
Entering Service Mode
19
Service Mode on Master Control
19
Navigating Service Mode: Master Control
19
Forced Operation: Master Control
35
Service Tool Setup
38
